VERIFACT K

MICROPHONE

INSTALLATION AND OPERATING INSTRUCTIONS

Page 1 of 4

K_mic_inst_12/14

6955 VALJEAN AVE, VAN NUYS, CA 91406

PH: (818)994-6498 / FAX: (818)994-6458

/ www.louroe.comtechsupport@louroe.com

®

®

®

®

®

DESCRIPTION

The Verifact Model K is a dynamic line level microphone

with adirectional pattern. The modified pattern is one in

which the audio pick up is more from the front of the

microphone and less from the sides and back. It is especially

designed for areas with excessive background noise or

where the ambient sound level is high. The V

®

erifact Model

K is pre-amplified, produces line level output and is

compatible with all Louroe audio base stations and interface

adapters.

When mounting, position the V

®

erifact K so that microphone

element is facing the desired area of coverage. Microphone

functions best when it is mounted close to the area to the

monitored, 3’ - 8’ away. A vibration pad is included and may

the use if the microphone wii be subject to vibration (eg:

transportation vehicles)

SPECIFICATIONS

Frequency Response

Output

Current Drain

100 Hz to 15 kHz

Line Level (0 dB, 600W @1kHz)

10 mA

Supply voltage12 Vdc

Weight

Shipping Weight

2.5 oz

1 lb

Dimensions 4 3/8”L x 2“W x 1 3/4”H

TypeDynamic, -58dBV@ 94dB SPL

Polar PatternModified Directional

IMPORTANT NOTICE

When this equipment is used as part of an

audio monitoring system, the law requires

that the public be given notice of AUDIO

MONITORING ON THE PREMISES. A

decal notice is included with each

microphone shipped.

Federal Law References:

Federal Regulations, US Code, Title 18.

Crime and Criminal Procedure, Sec 2510.

AUDIO

MONITORING

On

These Premises

®

LOUROE ELECTRONICS 6955 VALJEAN AVENUE, VAN NUYS, CA 91406TEL (818) 994-6498FAX 994-6458

website: www.louroe.com e-mail: sales@louroe.com

(818)

WARRANTY

LOUROE ELECTRONICS warrants that at the time of shipment products manufactured by LOUROE ELECTRONICS to be free of defects in material and workmanship.

Should a defect appear within two year (24 months) from date of shipment, LOUROE ELECTRONICS will, at its sole discretion, repair or replace the defective equipment.

This equipment shall not be accepted for repair or return without prior notification by LOUROE ELECTRONICS .

This warranty does not extend to any Louroe product that has been subjected to improper or incorrect installation, misuse, accident, or in violation of installation

instructions provided by LOUROE ELECTRONICS.

Returned shipments to LOUROE ELECTRONICS shall be at customer’s expense. LOUROE ELECTRONICS will return the equipment prepaid via best way.

®

®

®

®

®

®
