Louroe Model D-ML and D-V-ML are omni-directional, mic level low impedance, electret condenser microphones. They
can pick up normal sounds approximately 15’ away if mounted to a wall, or within a 30’ circle if ceiling mounted. The
microphone is mounted to the back of a single gang stainless face plate. Verifact D-V-ML is designed for correctional
facilities, or areas where vandalism is a concern. It contains the identical electronics as the Model D-ML Microphone but
is mounted to a 16 gauge stainless steel face plate. Microphone opening is a hooded audio port for providing protection
to the microphone. Tamper proof screws are included with the D-V-ML.
Both models come with pre-made 20’ cable with stereo plug for direct connect to the audio input of the IP camera.
Both Models D-ML and D-V-ML fit into a standard single gang electrical box (not supplied).
D-V-ML
Vandal Resistant
D-ML
Microphone
D-ML/D-V-ML
MICROPHONES
INSTALLATION AND OPERATING INSTRUCTIONS
6955 VALJEAN AVE, VAN NUYS, CA 91406
PH: (818)994-6498 / FAX: (818)994-6458
/ www.louroe.comtechsupport@louroe.com
®
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL (818) 994-6498 FAX 994-6458
website: www.louroe.com e-mail: sales@louroe.com
(818)
®
D_ML/D-V_ML_inst_12/14
DESCRIPTION
SPECIFICATIONS
Sensitivity
Frequency response
Output Impedence
Current drain
50 Hz to 8 kHz
Supply voltage
-45 dB/pa
1kW
0.8mA
1.8Vdc to 4.5Vdc
Weight
Shipping Weight
D-ML 6.5 oz D-V-ML 8 oz
1 lb
Dimensions (faceplate)
2 ¾ W x " 4 ½" H
Backbox Single gang electrical
box (not included)
