The Model Verifact L-DT is a bi-directional electret

condenser microphone with built-in preamp. It can pick

up normal sounds approximately 10 ft. away. Sound

pickup on both sides of the microphone is lower than

the front and back where the microphones are located.

Verifact L-DT produces low impedance line level

output and can be located up to 1,000’ from the Louroe

base station. It is primarily designed for ceiling

mounting but can also be installed on any type of flat

surface. The Verifact L-DT is compatible with all

Louroe Audio Base Stations or Louroe Audio Interface

Adapters.

PAGE 1 OF 4

NOTE:

Verifact L-DT Microphone is not recommended

for outdoor use or in areas with high moisture

content.

DESCRIPTION

SPECIFICATIONS

Sensitivity (mic)

Frequency response

Output

Current drain

-45dB

300 Hz to 10kHz

10mA

Supply voltage 12 Vdc

Microphone housing High impact ABS

Dimensions

Weight

Shipping Weight

4 3/8”L x 2 1/4”W x 1 1/5”H

2.5 oz

1 lb

Line Level (0 dB, 1KW @ 1kHz)

VERIFACT L-DT

AUDIO MONITORING SYSTEM

INSTALLATION AND OPERATING INSTRUCTIONS

6955 VALJEAN AVE, VAN NUYS, CA 91406

PH: (818)994-6498 / FAX: (818)994-6458

/ www.louroe.comtechsupport@louroe.com

L_DT_mic-inst_12/14

MIC ELEMENTS

IMPORTANT NOTICE

When this equipment is used as part of an

audio monitoring system, the law requires

that the public be given notice of AUDIO

MONITORING ON THE PREMISES. A

decal notice is included with each

microphone shipped.

Federal Law References:

Federal Regulations, US Code, Title 18.

Crime and Criminal Procedure, Sec 2510.

AUDIO

MONITORING

These Premises

WARRANTY

LOUROE ELECTRONICS warrants that at the time of shipment products manufactured by LOUROE ELECTRONICS to be free of defects in material and workmanship.

Should a defect appear within one year (12 months) from date of shipment, LOUROE ELECTRONICS will, at its sole discretion, repair or replace the defective equipment.

This equipment shall not be accepted for repair or return without prior notification by LOUROE ELECTRONICS .

This warranty does not extend to any Louroe product that has been subjected to improper or incorrect installation, misuse, accident, or in violation of installation

instructions provided by LOUROE ELECTRONICS.

Returned shipments to LOUROE ELECTRONICS shall be at customer’s expense. LOUROE ELECTRONICS will return the equipment prepaid via best way.
