INSTRUCTION MANUAL

GOOSENECK PAGING MICROPHONE -- DM518AM

Thank you for purchasing TOA’s Paging Microphone.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

1. GENERAL DESCRIPTION

The -518- is a gooseneck paging microphone with push--talk switch and remote control output. DMAMto

The microphone body is solidly constructed of metal -cast and designed to reduce switching and handling noise. die

2. APPEARANCE

3. CIRCUIT DIAGRAM

4. SPECIFICATIONS

Type

Moving coil microphone

Directivity

Unidirectional

Frequency Response

50 ,000 Hz –12

Sensitivity

-63 3 dB (0 dB=1V/Pa, 1kHz) dB ±

Rated Impedance

150, balanced Ω

Talk Switch

Short-ocircuit type, push- -talk switch (Normally-Open) to

Connection Cable

4 conductor (1 shielded) cable

Finish

Body: D-cast zinc, painted Metallic Gray ie

Head: Die-cast aluminum and zinc plated steel wire, painted Metallic Gray

Gooseneck: High carbon steel and aluminum alloy, electroplating Bright Chrome

Dimensions

ΦΦ1.56” x 6.38”] 39.5 62[x 1mm (Microphone body)

Weight

7 g (including connection cable)20

Accessories

Mounting screws …3 (3/4” length)

Note: The design and specications are subject to change without notice for improvement.

202210

Base part

*detachable with 5/8” thread

Gooseneck part

Push--talk switch to
