ATOLL ELECTRONIQUE

OWNER’S MANUAL ~ CONVERTERDAC200 Sig

ATOLL ELECTRONIQUEPage 5Page 4

1) XLR output (Right).

2) Analog output (Right).

3) Analog output (Left).

4) XLR output (Left).

5) Digital output (coaxial).

6) Digital output (optical).

7) Digital input 3 (optical).

8) Digital input 2 (optical).

9) Digital input 1 (optical).

10) Digital input 3 (coaxial).

11) Digital input 2 (coaxial).

12) Digital input 1 (coaxial).

13) AES input.

14) USB input (type B).

15) Power plug.

16) Switch ON/OFF.

CONNECTINGREMOTE CONTROL

DETAILS OF FUNCTIONS

Reminder: do not make any connections when your device is turned on.

17) Sources selection keys.

18) Filters setup keys (see details beside): selection is made with keys (17).

19) Headphones output (jack 3,5mm) (linking the headphones shut down

the Output signals).

NB : When you connect a headphones, regardless of the BY-PASS

mode, you’ll switch to volume management mode (BY-PASS OFF) in

order to manage the volume level of the headphones.

20) Display: selected source shows on the left and frequency sampling on

the right. When no signal is detected display shows UNLOCK.

21) Volume control keys &

+

(when BY-PASS OFF) from 0 to 80

22) ON/stand-by key.

The remote control is equipped with 2 Lithium CR2025 batteries. This remote control

is also able to drive all others ATOLL’s products: CD players; Tuner; Integrated or

Preamplifier. (See those manuals for details).

23) Volume keys

+

&

(*)

.

24) Standby/ON key.

25) Source selection keys

+

&.

23

24

25

(*)

Volume control is possible only when BY-PASS OFF. When changing the volume, level

is displayed shortly, then the display shows the sampling frequency.

BLUETOOTH®

FILTERS SETUP

Your appliance allows the reception of audio signals sent since any devices having a

Bluetooth transmitter (Smartphone, tab, computer…).

First time association:

• Activate the Bluetooth® connectivity of your emitter device.

• Select the Bluetooth® (BT) input of DAC200 Sig: unlock symbol

BT

appears.

• Select your appliance on the list of possible receiver (named DAC200 Sig).

• Once the connection is made, the lock symbol

BT

appears.

The whole audio signals of your device source will then be transmitted towards your

DAC200 Sig. Your emitter device will remain associated until you unlock the DAC200

Sig with your Smartphone or switch off your amplifier.

Association of another emitter:

• To connect another emitter, you’ll need to disconnect the first emitter. The quality

of reception of the signal depends on the power of the Bluetooth emitter and

the distance between the 2 devices.

Avoid being more than 5 meters of your DAC200 Sig for a correct reception without

any risks of signal cuts.

While pressing key (18) you can choose different kinds of digital filters which you can select

with the 17’s keys:

• Standard: fast roll-off, minimum phase filter

• Fast lin: fast roll-off, linear phase filter

• Slow min: soft roll-off, minimum phase filter

• Slow lin: soft roll-off, linear phase filter

• Apodizing: fast roll-off by apodizing and linear phase filter

• Hybrid: fast roll-off and minimum phase filter

12345678910111213141516

1718

19

202122
