Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: August 6, 2019 8:15 AM

Product Diagram (PWRSTRPCLMP)

ComponentFunction

1Adjustable Clamp

• Used to hold the in place.Power Strip

• The can support devices Adjustable Clamp

between 40 mm - 60 mm (1.6” - 2.4”) wide.

2EVA Form Pad (x 2)• Used to prevent surface scratches.

3C-Clamp

• Used to secure the to Power StripDesk Clamp

the edge of a surface.

• Clamps to surfaces up to 50 mm (2”) thick.

4Thumb Screw

• Used to tighten the securing it to the C-Clamp

surface.

5Silicone Pad (x 2)• Used to securely grip the clamped .Device

Requirements

For the latest requirements, please visit www.startech.com/PWRSTRPCLMP

Installation

1. Align the with the edge of the surface and slide it over the edge of the C-Clamp

surface.

2. Using the tighten the until the is pressed tightly Thumb ScrewC-Clamp C-Clamp

against the surface.

Power Strip Desk Clamp

3. Slide the (e.g. Power Strip) into the , securing the DeviceAdjustable ClampDevice

in place. The will adjust to the size of the , between Power Strip Desk ClampDevice

40 mm - 60 mm (1.6” - 2.4”) wide.

Adjusting the Power Stripe Desk Clamp

4. Route the down the back of the Power CablePower Strip Desk Clamp and through

the .Cable Management Clip

Routing the Cable

1

2

3

4

5
