Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: July 4, 2019

Product Diagram (LTSTND)

Angled View

PartFunction

1Top Plate• A platform for a Laptop

2Upper Leg

• Attaches to the Top Plate

• Congurable with three height-adjustment

settings

3

Cable-Management

Slots

• Organize and route Cables

4Lower Leg• Attaches to the Upper Leg

5

Height-Adjustment

Knob

• Secure the and Upper LegsLower Legs

together

• Can be removed to adjust height settings

Laptop Stand - Height Adjustable

Requirements

• Clean, Flat, and Stable Surface x 1

For the latest requirements please visit: . www.startech.com/LTSTND

Installation

Assembly

1. Place the , top side down, onto a .Top PlateClean, Flat, and Stable Surface

Note: The lip on the can overhang o the edge of the for a level Top PlateSurface

installation.

2. Place the onto the . Ensure the in the Upper LegsTop PlateHolesUpper Legs

are aligned with the on the . The slanted portion of the Threaded PostsTop Plate

Upper LegsTop Plate should be aligned with the slanted portion of the .

3. Secure the to the using two for each side. Fasten the Upper LegsTop Plate,Nuts

NutsWrench using the . (Figure 1)

Note: Align the outside edges of the with the outside edges of the Upper LegsTop

PlateNuts before tightening the .

1

4

2

5

3

Figure 1

Wrench

Nut

Upper Leg

Top Plate

Threaded

Post
