Pleasegotoforproductcleaningtips.Gototheselection.

Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.

IntegratedLED38W

20-30minutes

Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtoensureallpartsare

present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactyouroriginalplaceofpurchase.

www.quoizel.comCare+Maintenance

ToolsRequired:

LightSource:

EstimatedAssemblyTime:

Preparation:

1of1

PCBD8526EK

FINISH:EARTHBLACK

NOTE:ALLDIMENSIONSAREROUNDEDUP

TOTHENEAREST1/4"

PackageContents

B

MountingScrew

x4

InnerBackplate

x1

A

C

FixtureBody

x1

D

Shade

x1

F

Bracket

x2

D

F

E

ShadeHolder

STEP1InstallInnerBackplateandFixtureBody-

A.PassthesupplywiresandgroundwirethroughtheInnerBackplate

(A).AttachtheInnerBackplate(A)tooutletboxwiththeheadof

greengroundscrewfacingyou.Secureitwithoutletboxscrews

(notincluded).Tightenuntilsnug

B.RefertoStep2forwiringconnections.

C.AttachtheFixtureBody(C)overtheInnerBackplate(A)andsecure

withMountingScrews(B).Tightenuntilsnugwithscrewdrivers.

.

A

Figure1

OutletBoxScrew

(notincluded)

C

B

STEP3InstallShadetoFixtureBody-

A.InsertShade(D)intotheShadeHolderproperly.

B.PlaceBracket(F)overthesideoftheShadeHolder,lineupthehole

ontheBracket(F)andthemountingholeontheShadeHolder,

securebythreadingLockScrew(E)intothemountinghole,tighten

untilsung.

Yourfixtureisnowassembledandreadytouse.Enjoy!

E

LockScrew

x4

ForStylePCBD8526EK

InstallationGuide#IS-PCBD8526EK

WarningsandCautions

Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.

Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly

recommendthatalicensed,professionalelectricianperformtheinstallation.

2019QuoizelInc.

ReleasedDate:2019-01-22

visituson-lineatwww.quoizel.com

OutletBox

SupplyWiresand

GroundWire

STEP2-WireConnections

A.Wrapbareorgreengroundwirearoundgreengroundscrewonthe

crossbar,nolessthan2inchesfromtheendofthewire.Tightenthe

greengroundscrew.

B.Usestandardwireconnectors(notincluded)tomakeallwire

connections.Twistconnectorsuntilwiresaretightlyjoinedtogether.

Wrapeachconnectionwithapprovedelectricaltapeandcarefully

stuffalltheconnectedwiresintotheOutletBox.

Figure2

GreenGroundScrew

ontheCrossbar

Whitewire

fromoutletbox

Whitewire

fromfixture

Blackwirefrom

outletbox(orRed)

Blackwire

fromfixture

Bare,orGreen

Groundwire

fromoutletbox

Groundwire

fromFixture

Figure3

26”

4.5”

6.5”

4.5”
