WarningsandCautions

1of2

AssemblyInstructionSheet#IS-AS1716PN

ForStyleAS1716PN

ThankyouforpurchasingaQuoizelproduct.

Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-631-273-2700

orvisituson-lineatwww.quoizel.com

2015QuoizelInc.

Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.

Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly

recommendthatalicensed,professionalelectricianperformtheinstallation.

Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocoolbeforeremoval.Donotsubject

glasspartstoanyshockwhileinoperationorshatteringmayresult.

August2015

Pleasegotoforproductcleaningtips.Gototheselection.

(4)B10CandelabraBase60WMaximum.

30-45minutes

Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtobesureallpartsare

present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement

parts.

www.quoizel.comCare+Maintenance

LightSource:

EstimatedAssemblyTime:

Preparation:

ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.

STEP5-InstallShadetoFixture

A.Thisfixtureusescandelabra

bulbwithscrewbase.Maximum

60watts.Insertbulbandscrew

snuglyintoplace.

Yourfixtureisnowassembled

andreadytouse.Enjoy!

Figure5

Socket

Bulb

PackageContents

B

Crossbar

x1

LockWasher

x1

HexNut

x2

Nipple

x1

A

STEP2InstallCrossbar-

A.A)AttachtheCrossbar(totheOutletBoxwiththeheadoftheGreen

GroundScrewfacingyou.SecureitwithOutletBoxScrews(not

included)Tightenuntilsnug..

Figure1

OutletBox

OutletBoxScrew

(notincluded)

GreenGround

Screw

G

Fixture

Body

x1

STEP3InstallFixtureBody-

*Pliersisrequiredforthisstep.

A.ThreadHexNut(C)tothemiddleoftheNipple(D).PlaceLock

Washer(B)overtheNipple(D)andthenthreadtheNipple(D)into

theCrossbar(A)untiltheNipple(D)isabout0.375”abovethe

Crossbar(A).

Figure3

C

D

LockNut

x1

E

A

B

C

D

D

STEP4-WireConnections

A.Usestandardwireconnectors(notincluded)tomakeallwire

connections.(Connectorsarenotincludedwithfixture.)Twist

connectorsuntilwiresaretightlyjoinedtogether.Wrapeach

connectionwithapprovedelectricaltapeandcarefullystuffallthe

connectedwiresintotheOutletBox.

Whitewire

fromsupply

Whitewire

fromfixture

Blackwirefrom

supply(orRed)

Blackwire

fromfixture

Groundwire

fromsupply

Groundwire

fromfixture

Figure4

F

SideArm

x3

STEP1AssembleSideArms-

A.RemoveHexNutandWasherfromtheSideArm(F).Attachtheloop

endoftheSideArm(F)totheinsidearmoftheFixtureBody(G).

HexNut

Washer

F

G

Ceiling

Canopy

Inside

Arm

Loop

Passthenippleatthetop

endoftheSideArm(F)

throughtheholeonthe

CeilingCanopy.Placethe

Washerbackontotopend

oftheSideArm(F)andby

usingSpanner(H)thread

theHexNutontotheSide

Arm(F)tosecurethem

together.Handtightenuntil

snug.

Figure2

A

Ceiling

Canopy

G

(Step3Continued)

B.PlacetheCeilingCanopyoftheFixture

Body(G)overtheNipple(D)againstthe

ceilingtodeterminethecorrectposition

oftheNipple(D).ThreadtheLockNut(E)

ontotheNipple(D).AdjusttheNipple(D)

toallowtheCeilingCanopyofthe

FixtureBody(G)torestagainst

theceilingwhenheldinplaceby

theLockNut(E).

C.RemovetheLockNut(E)andthe

FixtureBody(G).TightentheHex

Nut(C)againsttheCrossbar(A)

tosecureinplace.

D.RefertoStep4forwire

connections.

E.PlacetheCeilingCanopyofthe

FixtureBody(G)backoverthe

Nipple(D)andsecurewiththe

LockNut(E).Handtightenuntil

snug.

H

Spanner

x1

H
