Sivu 1/2
Output | Output | Salida |
Puissance de sortie | Potenza |
Utgång | Выход | 出力 |
Input | Eingang | Entrada |
Puissance d’entrée | Ingresso |
Ingång | Вход | |入力
Warranty | Garantie | Garantía |
Garantie | Garanzia | Garanti |
Гарантия | | 保証
Model | Modell | Modelo | Modèle |
Modello | Modell | Модель | |原型
WCG2X32-EU
WCG2X32SGR-EU
Dimensions | Dimensionen | Dimensiones |
Dimensions | Dimensioni| | Mått | Габариты |
大きさ |
48.5 x 47.3 x 27.7mm (H x D x W)
Weight | Gewicht | Peso | Poids | Vikt
Вес | Peso | | 重量
73g
Output | Output | Salida |
Puissance de sortie | Potenza |
Utgång | Выход | 出力 |
32.0W Rapid Power
2 Port USB-C + USB-A GaN Charger
Designed in Australia. Manufactured in China
1
1
3
2
2
30.0W
3
18.0W
Single Port
USB-C #1 single output: PD3.0 (5.0V,9.0V/3.0A, 12.0V/2.52A) -30.0W Max*
USB-A #2 single output: 3.6V,6.0V/3.0A, 6.0V,9.0V/2.0A, 9.0V,12.0V/1.5A -18.0W Max
Dual Port
USB-C: 5.0V/3.0A, 9.0V/2.22A, 12.0V/1.67A -20.0W
USB-A: 5.0V/2.4A -12.0W
* USB-C #1 USB-A#2 Derated when both ports active as follows: 20.0W + 12.0W
Enkel port
USB-C #1 enkel utgång: PD3.0 (5.0V,9.0V/3.0A,12.0V/2.52A) -30W Max*
USB-A #2 enkel utgång: 3,6V,6,0V/3,0A, 6,0V,9,0V/2,0A, 9,0V,12,0V/1,5A -18,0W Max.
Dubbla portar
USB-C: 5.0V/3.0A, 9.0V/2.22A, 12.0V/1.67A -20.0W
USB-A: 5.0V/2.4A -12.0W
* Avdramatiserat när båda portarna är aktiva enligt följande:
USB-C #1 USB-A#2 20.0W + 12.0W
Single Port
USB-C # 1 Einzelleistung: PD3.0 (5.0V,9.0V/3.0A, 12.0V/2.52A) -30.0W max *
USB-A # 2 Einzelleistung: 3.6V,6.0V/3.0A, 6.0V,9.0V/2.0A, 9.0V,12.0V/1.5A -18.0W max
Dual Port
USB-C: 5.0V/3.0A, 9.0V/2.22A, 12.0V/1.67A -20.0W
USB-A: 5.0V/2.4A -12.0W
* Reduziert, wenn beide Ports wie folgt aktiv sind:
USB-C # 1 + USB-A # 2 20.0W 12.0W
Puerto único
Salida única USB-C #1: PD3.0 (5.0V,9.0V/3.0A, 12.0V/2.52A) -30.0W Max*
Salida única USB-A # 2: 3.6V,6.0V/3.0A, 6.0V,9.0V/2.0A, 9.0V,12.0V/1.5A -18.0W Max
Puerto dual
USB-C: 5.0V/3.0A, 9.0V/2.22A, 12.0V/1.67A -20.0W
USB-A: 5.0V/2.4A -12.0W
* : Reducido cuando ambos puertos están activos de la siguiente manera
USB-C # 1 + USB-A # 2 20.0W 12.0W
Port Unique
USB-C #1 sortie unique: PD3.0 (5.0V,9.0V/3.0A, 12.0V/2.52A) -30.0W Max*
USB-A #1 sortie unique: 3.6V,6.0V/3.0A, 6.0V,9.0V/2.0A, 9.0V,12.0V/1.5A -18.0W Max
Port Double
USB-C: 5.0V/3.0A, 9.0V/2.22A, 12.0V/1.67A -20.0W
USB-A: 5.0V/2.4A -12.0W
*Puissance réduite quand les deux ports sont ainsi activés:
USB-C # 1 + USB-A # 2 20.0W 12.0W
Porta singola
USB-C #1 porta singola: PD3.0 (5.0V,9.0V/3.0A, 12.0V/2.52A) -30.0W Max*
USB-A #2 porta singola: 3.6V,6.0V/3.0A, 6.0V,9.0V/2.0A, 9.0V,12.0V/1.5A -18.0W Max
Porta doppia
USB-C: 5.0V/3.0A, 9.0V/2.22A, 12.0V/1.67A -20.0W
USB-A: 5.0V/2.4A -12.0W
*Quando entrambe le porte vengono utilizzate, la tensione si riduce così:
USB-C # 1 + USB-A # 2 20.0W 12.0W
1 2
1
2
3
USB-A Ladestation - 18.0W max
Salida de carga USB-A - 18.0W máx.
USB-A charging outlet - 18.0W max
Source d’alimentation USB-A - 18.0W max
Presa di carica USB-A - 18.0W max
USB-A 充電 - 最大18.0W
USB-A - 18.0
USB-C Ladestation - 30.0W max
Salida de carga USB-C: 30.0W máx.
Source d’alimentation USB-C -30.0W max
Гнездо зарядки USB-C – макс. 30.0 Вт
Индикатор питания
USB-C charging outlet - 30.0W max
USB-C 充電 - 最大30.0W
Porta USB-C carica max -30.0W
30.0
Power indicator
Betriebsanzeige
Indicador de encendido
Indicateur de Batterie
Indicatore di corrente
電源インジケーター
Гнездо зарядки USB-A – макс. 18.0 Вт
1
32.0W Adaptateur à charge rapide GaN
Caricatore rapido GaN 32.0W
32.0W Rapid Power GaN Charger 32.0W Snabb Eekt GaN-laddare
USB-C-laddningsuttag - 30,0 W max.
USB-A-laddningsuttag - 18,0 W max.
Strömindikator
32.0W Schnellladegerät GaN
Cargador GaN de potencia rápida de 32.0W
Guide d’utilisation
User Manual Användarhandbok
Benutzerhandbuch
Manual del Usuario
Manuale utente
ユーザーマニュアル
2
32.0W 高速充電 GaN チャージャー
32.0
Устройство ускоренной зарядки на
полупроводниках GaN мощностью 32.0 Вт
Руководство пользователя
12.03.09.05.0) 3.0
#1
-30.0 2.52 *
3.06.03.6
#2
6.0 -18.01.512.09.02.0 9.0
2.229.03.05.0
12.0 -20.01.67
-12.02.45.0
* :
12.0 #220.0 #1
100-240VAC 50~60Hz 1.0A Max 100-240VAC 50~60Hz 1.0A Max
100-240VAC 50~60Hz 1.0A Máx
100-240VAC 50~60Hz 1.0A Max
100-240VAC 50~60Hz 1.0A Max
100-240VAC 50~60Hz 1.0A Max
100-240V AC 50~60Hz 最大1.0A
100 - 240
50 ~ 60 1.0
シングルポート
USB-C #1 単一出力:PD3.0 (5.0V,9.0V/3.0A, 12.0V/2.52A) - 最大30.0W *.
USB-A #2 単一出力:3.6V,6.0V/3.0A,6.0V,9.0V/2.0A,9.0V,12.0V/1.5A - 最大18.0W
デュアルポート
USB-C: 5.0V/3.0A、9.0V/2.22A、12.0V/1.67A -20.0W
USB-A: 5.0V/2.4A -12.0W
* 両ポートがアクティブな場合は次の様に遅延します。
USB-C#1 USB-A#2 20.0W + 12.0W
Только один порт
USB-C №1 только один порт: PD3.0 (5.0,9.0 В/ 3.0 A, 12.0 В/ 2,52 A) -30.0
Вт макс.*
USB-A №2 только один порт: 3.6 В, 6.0 В/ 3.0 A, 6.0V, 9.0 В/ 2.0A, 9.0V, 12.0
В/ 1.5 A -18.0 Вт макс.
Оба порта
USB-C: 5.0 В/ 3.0 A, 9.0 В/ 3.0A, 12.0 В/ 1.67A -20.0 Вт
USB-A: 5.0 В/ 2.4 A -12.0Вт
*При подключении обоих портов значения снижаются до следующих:
USB-C №1 USB-А №2 20.0 Вт + 12.0 Вт
~100-240 В, 50/60 Гц, 1,0 A макс.
Schnellstartanleitung
Quick Start Guide
Guida Rapida
Guide de démarrage
rapide
Guía de inicio rápido
Snabbstartguide
クイックスタートガイド
Краткое руководство
пользователя
Package Contents | Packungsinhalt | Contenido del Paquete |
Contenu du Colis | Contenuto confezione | Paketets innehåll |
Содержимое упаковки | パッケージ内容 |
Specifications | Spezifikationen | Especificaciones |
Caractéristiques techniques | Specificazioni | Specifikationer |
Технические характеристики | | 仕様書
Specifications | Spezifikationen | Especificaciones |
Caractéristiques techniques | Specificazioni | Specifikationer |
Технические характеристики | | 仕様書
2 Jahre
2 Años
2 Years 2 Ans
2 Anni
2 år
2年
2 года
2
(
32.0W Rapid Power
2 Port USB-C + USB-A GaN Charger
Schnellstartanleitung
Quick S tart G uide
Guida Rapida
Guide de démarrage
rapide
Guía de inicio rápido
Snabbstartguide
クイックスタートガイド
Крат кое руко водство
пользователя
EN
Troubleshooting
Problem Solution
Devices charges
slowly
Ensure you connect high powered devices such as Tablets and smartphones to the top USB-C port.
This port is designed for high power charging and provides more power than the USB-A port below it.
Ensure you use a USB-C cable rated at 3.0A or above when charging. Most USB-C cables support
charging at up to 3.0A (60.0W), but some only support lower charging currents and will not allow
some tablets to charge at full speed.
Congratulations on purchasing this quality ALOGIC product. To get the most out of your purchase, please take the time to
read these instructions before use.
This Product supports the latest USB-C Power delivery (PD) charging standard to allow high power USB-C devices such as
Ultrabook, Chromebook, MacBook Air/Pro, tablets & phones to be charged at up to 30.0W or just can easily charge USB-A
enabled device to up to 18.0W.
This charger also allows you to simultaneously charge up to two USB devices through USB-C & USB-A port.
USB-C Power Delivery is a new, multi-voltage charging standard that dynamically negotiates power output over a USB-C
connection allowing you to safely and eciently recharge a wide range of compatible devices from a
single charger.
Instructions
The USB-C port can charge devices at up to 30.0W when used on its own. When both ports are in use the maximum output
available is reduced to 20.0W. Any device plugged to USB-A Port can be charged at up to 18.0W when any device is
pugged into USB-C port for charging then USB-A port downgrades to 12.0W giving the total output of 32.0W across both
the USB-C & USB-A ports
Note
Plug the wall charger into a power outlet.
Connect your Ultrabook, Chromebook, MacBook, tablet, phone or other high-powered devices such as game
console to the USB-C outlet. This outlet will charge devices at up to 30.0W.
Use a USB-C 5.0A rated cable to ensure the Tablet or smartphone charges at the fastest speeds available.
Connect lower powered USB-A devices such as phones to the USB-A outlet. The second USB-A port will charge
devices at up to 18.0W.
Unplugging your devices when they have finished charging is recommended to prolong the life of the batteries.
Using the Charger
(Refer to the images on the previous pages)
1
2
3
4
