Ceiling tile
Grille and bezel
Grille and bezel
seismic restraint
Seismic restraint anchor tab
Euroblock connector
Cover plate
Strain relief (not included) may
be used with cover plate.
Tile bridge
Euroblock jack
Baffle
Styrofoam installation aid/paint mask
Speed Wing™ mounting arms
Cover plate clamping screw
Signal wire
Box contents
1 Speaker
1 Euroblock connector
1 Grille and bezel
1 Styrofoam installation aid/paint mask
1 Cover plate
1 Tile bridge
Install Instructions For:
CM400i, CM500i, CM590i, CM600i, CM690i, CM800i & CM890i speakers
Min
6.4 mm (0.25 in)
Max
42.9 mm (1.69 in)
Ceiling thickness tolerances
Do not spec or install speaker near support beam, ventilation duct or
other structure that may interfere with speaker function or dispersion.
Warning Warning
SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for
optimum audio performance, installer must follow all directions issued by SoundTube Entertainment.
© 2009 SoundTube Entertainment, Inc. All rights reserved. PN INS-CMI Rev05.26.09
1.435.647.9555
|| 800.647.TUBE
www.soundtube.com
CM400i, CM500i, CM600i, CM690i, CM800i, CM890i – UL listed 1480 & 2043
