DisplayPort EDID Emulator

DESIGNED TO EMULATE AND

STORE THE EDID OF A VIDEO

DISPLAY

Quick Start Guide

VIDEO

FormatDisplayPort 1.1 and 1.2

Maximum Pixel Clock275 MHz

Input InterfaceDisplayPort (male)

Output InterfaceDisplayPort (female)

ResolutionUp to 3840 x 2160 @ 30 Hz

DDCvia AUX

Input EqualizationAutomatic

Input Cable LengthUp to 15 ft.

Output Cable LengthUp to 15 ft.

OTHER

Dimensions2.8” x 1” x .33”

Weight.7 oz

ApprovalsUL, CE, ROHS Compliant

Operating Temp.+32 to +104°F (0 to +40°C)

Humidity20% to 80% (non condensing)

Storage Temp.-4 to 140°F (-20 to +60°C)

Storage HumidityUp to 95% (No Condensation)

Compliance EMCFCC (Class A), CE (Class A), ICES-003

Environmental

Compliance

RoHS2 (CE)

Support Warranty1-year

NOTICE

The information contained in this document is

subject to change without notice. SmartAVI makes

no warranty of any kind with regard to this material,

including but not limited to, implied warranties of

merchantability and tness for particular purpose.

SmartAVI will not be liable for errors contained

herein or for incidental or consequential damages in

connection with the furnishing, performance or use of

this material.

No part of this document may be photocopied,

reproduced, or translated into another language

without prior written consent from SmartAVI

Technologies, Inc.

800.AVI.2131, 702.800.0005

2455 W Cheyenne Ave, Suite 112

North Las Vegas, NV 89032

SmartAVI.com

TECHNICAL SPECIFICATION

SM-EDP

WHAT’S IN THE BOX

PART NO.DESCRIPTIONQ-TY

SM-EDP-S1

DP EDID Emulator.

Includes: [SM-EDP]

Quick Start Guide1
