Sivu 1/8
Edge Portion
Pad Face
Output Jack
Bow Portion
Contents of the Package
❑PD-6 (pad unit)
❑Connection Cable (monaural)
■Owner's Manual (this manual)
Stand Fixing Screw
Stand Fixing Screw
Head
Output Jack
Holder
Holder
Contents of the Package
❑CY-6 (cymbal pad unit)
❑Connection Cable (stereo)
❑Wing Nut
❑Felt Washer
❑Stopper
■Owner's Manual (this manual)
Before using CY-6/PD-6, you need to make the settings for
the percussion sound module (p. 7).
Owner's Manual
Thank you and congratulations on your choice of the Roland Cymbal Pad CY-6/Pad PD-6.
02564567 ’01-6-F3-21N
Copyright © 2001 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any
form without the written permission of ROLAND CORPORATION.
Before using this unit,
carefully read the
sections entitled:
“USING THE UNIT
SAFELY” (p. 2–3) and
“IMPORTANT NOTES”
(p. 3). These sections
provide important
information concerning
the proper operation of
the unit. Additionally, in
order to feel assured
that you have gained a
good grasp of every
feature provided by
your new unit, Owner’s
manual should be read
in its entirety. The
manual should be
saved and kept on
hand as a convenient
reference.
2
USING THE UNIT SAFELY
001
• Before using this unit, make sure to read the
instructions below, and the Owner’s Manual.
................................................................................................
002a
• Do not open or perform any internal
modications on the unit.
................................................................................................
003
• Do not attempt to repair the unit, or replace
parts within it (except when this manual
provides specic instructions directing you
to do so). Refer all servicing to your retailer,
the nearest Roland Service Center, or an
authorized Roland distributor, as listed on
the “Information” page.
................................................................................................
004
• Never use or store the unit in places that are:
• Subject to temperature extremes (e.g.,
direct sunlight in an enclosed vehicle, near
a heating duct, on top of heat-generating
equipment); or are
• Damp (e.g., baths, washrooms, on wet
oors); or are
• Humid; or are
• Exposed to rain; or are
• Dusty; or are
• Subject to high levels of vibration.
................................................................................................
005
• This unit should be used only with a rack or
stand that is recommended by Roland.
................................................................................................
006
• When using the unit with a rack or stand
recommended by Roland, the rack or stand
must be carefully placed so it is level and
sure to remain stable. If not using a rack or
stand, you still need to make sure that any
location you choose for placing the unit
provides a level surface that will properly
support the unit, and keep it from wobbling.
................................................................................................
011
• Do not allow any objects (e.g., ammable
material, coins, pins); or liquids of any kind
(water, soft drinks, etc.) to penetrate the unit.
................................................................................................
013
• In households with small children, an adult
should provide supervision until the child is
capable of following all the rules essential for
the safe operation of the unit.
................................................................................................
014
• Protect the unit from strong impact.
(Do not drop it!)
................................................................................................
Used for instructions intended to alert
the user to the risk of injury or material
damage should the unit be used
improperly.
* Material damage refers to damage or
other adverse effects caused with
respect to the home and all its
furnishings, as well to domestic
animals or pets.
Used for instructions intended to alert
the user to the risk of death or severe
injury should the unit be used
improperly.
The ● symbol alerts the user to things that must be
carried out. The specic thing that must be done is
indicated by the design contained within the circle. In
the case of the symbol at left, it means that the power-
cord plug must be unplugged from the outlet.
The symbol alerts the user to important instructions
or warnings.The specific meaning of the symbol is
determined by the design contained within the
triangle. In the case of the symbol at left, it is used for
general cautions, warnings, or alerts to danger.
The symbol alerts the user to items that must never
be carried out (are forbidden). The specic thing that
must not be done is indicated by the design contained
within the circle. In the case of the symbol at left, it
means that the unit must never be disassembled.
3
IMPORTANT NOTES
291a
In addition to the items listed under “USING THE UNIT SAFELY” on page 2–3, please read and observe the
following:
Placement
354a
•Do not expose the unit to direct sunlight, place it
near devices that radiate heat, leave it inside an
enclosed vehicle, or otherwise subject it to
temperature extremes. Excessive heat can deform or
discolor the unit.
355
•To avoid possible breakdown, do not use the unit in
a wet area, such as an area exposed to rain or other
moisture.
356
•Do not allow rubber, vinyl, or similar materials to
remain on the piano for long periods of time. Such
objects can discolor or otherwise harmfully aect
the nish.
357
•Do not put anything that contains water (e.g.,
ower vases) on the piano. Also, avoid the use of
insecticides, perfumes, alcohol, nail polish, spray
cans, etc., near the unit. Swiftly wipe away any
liquid that spills on the unit using a dry, soft cloth.
Maintenance
401a
•For everyday cleaning wipe the unit with a soft, dry
cloth or one that has been slightly dampened with
water. To remove stubborn dirt, use a cloth
impregnated with a mild, non-abrasive detergent.
Afterwards, be sure to wipe the unit thoroughly
with a soft, dry cloth.
402
•Never use benzine, thinners, alcohol or solvents of
any kind, to avoid the possibility of discoloration
and/or deformation.
Additional Precautions
553
•Use a reasonable amount of care when using the
unit s buttons, sliders, or other controls; and when ’
using its jacks and connectors. Rough handling can
lead to malfunctions.
558d
•This instrument is designed to minimize the
extraneous sounds produced when it s played. ’
However, since sound vibrations can be transmitted
through oors and walls to a greater degree than
expected, take care not to allow these sounds to
become a nuisance to neighbors, especially when
performing at night and when using headphones.
104
•Try to prevent cords and cables from
becoming entangled. Also, all cords and
cables should be placed so they are out of the
reach of children.
................................................................................................
106
•Never climb on top of, nor place heavy
objects on the unit.
................................................................................................
118
•Should you remove wing nut (for CY-6),
washers (for CY-6), or stand xing screw (for
PD-6) make sure to put them in a safe place
out of children's reach, so there is no chance
of them being swallowed accidentally.
................................................................................................
