Features
USB Type-C Male (Connect to a host computer)
Rocstor introduces the Type-C 6-in-1 hub with HDMI, 2 USB-A, Type-C data, RJ45, and
Type-C female port, oering a versatile solution for extending the port capabilities of
Type-C or Thunderbolt hosts (PC/Laptop/Mobile phone, etc.), especially benecial for
those with a single Type-C port. This hub facilitates HDMI video output at a maximum
resolution of 4k/60Hz while concurrently transferring USB 3.1 Gen2 data at a maximum
speed of 10Gbps. With 2 USB-A ports and a Type-C data port, you can connect up to 3
USB devices simultaneously. The RJ45 port provides the host with access to Gigabit
Ethernet. Additionally, the Type-C female port supports PD 3.0 with a maximum power
delivery of 100W PD Charging. Compatible with all DP Alt mode supported Type-C
hosts, this hub ensures seamless compatibility and enhanced functionality.
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in it:
• Main Unit x1
• User Manual
HDMI
• Supports HDMI max 4K/60Hz
• Supports 8/10/12 bit color depth output
• Supports output pixel format
RGB/YCbCr4:4:4/YCbCr4:2:2/YCbCr4:2:0
• Supports dynamic HDR
• Supports HDCP2.3
Note: The actual resolution supported is
determined by the host and the Display.
Upstream:
Downstream:
• Supports DP1.4 Alt mode,downward compatible with DP1.2 Alt mode
• Supports USB3.0/2.0 data transmission (transfer speed: Max 10Gbps)
• Supports transmission of DP Alt Mode video up to 4K/60Hz Simultaneously
Note: To get max bandwidth, the host should support DP1.4 Alt mode & DSC
USB-A X2
• Max 10Gbps data transmission per port
• Supports max 7.5W(5V/1.5A)
downstream charging the port close to
Type-C male port, another port supports
max 900mA downstream charging.
• 2 USB-A port share max 12 W(5V/2.4A),
the 2 USB-A port and the Type-C data
port share max 13W(5V/2.6A)
• Supports short-circuit, over-current,
over-voltage protection
RJ45 X1
• Supports Gigabit
Ethernet,10M/100M/1000M
• Supports Wake-On-LAN
• Supports full duplex ow control
• Light indicates the state, no light when
no Internet connected, orange light
turns on when network connection is
established, white light ashes when
transmitting data
Type-C Female X1
(for PD Charging & Data)
• Supports max 100W PD charging
• Supports PD3.0 Fast Role Swap, the
connected device will not get
disconnected while plugging out
PD Adapter
• 15W is dedicated to the functioning of
this product, the rest power (max 85W)
will be passed to charge for the host
Type-C Data 10G X1
(Close to HDMI)
• Max 10Gbps data transmission
• Supports max 7.5W(5V/1.5A)
downstream charging
• Supports short-circuit, over-current,
over-voltage protection
Package Contents
Specication
Input
Output HDMI Female x1
Type-C data 10G p1-x1
USB-A 10G x2
RJ45 x1
Type-C Female x 1(for PD Charging)
Type-C Male x1
3 Years
Operating Temperature
Storage Humidity
Storage Temperature
Operating Humidity
0°C to 45°C (32°F to 113°F)
5% to 90 % RH (no condensation)
-10°C to 70°C (14°F to 158°F)
10% to 85% RH (no condensation)
Introduction
Environmental
Input / Output Connector
Certications FCC, CE
Regulatory Approvals
User Manual English Version
Accessory Adapter
Warranty
Limited Warranty
Operating Temperature
Size
4.7x1.9x0.6in (120x50x15.5mm)
Mechanical
Weight 3.7lbs (105g)
®
Type-C to HDMI/USB-A 10GX2/Type-C data/RJ45/
PD Charging with DP1.4 Alt mode
User Manual
Y10A319-S1
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
