Lue alta 📖 käyttöohje suomeksi merkille Rocstor Y10A311-S1 (2 sivua) kategoriassa USB-keskitin. Tämä opas oli hyödyllinen 47 henkilölle ja sai 4.3 tähden keskimäärin 24 käyttäjältä
Sivu 1/2
Features
Rocstor’s ultimate connectivity solution: the Type-C 6-in-1 Hub. Seamlessly expand the
port options of your Type-C or Thunderbolt 3 host, whether it's a PC, laptop, or mobile
phone. Designed especially for devices with a single Type-C port, this hub oers
unrivaled versatility. Equipped with HDMI, 2 USB-A, RJ45, Type-C data, and Type-C PD
charging female ports, this hub covers all your connectivity needs. Its DP1.4 Alt mode
supported IC ensures crystal-clear HDMI video output, supporting resolutions up to 4k
at 60Hz. Plus, enjoy lightning-fast USB 3.1 data transfer speeds of up to 5Gbps.
Connect up to three USB devices simultaneously with the two USB-A and Type-C data
ports. And with the RJ45 port, gain access to Gigabit Ethernet for reliable, high-speed
internet connectivity. Need to power up your device? The Type-C female port supports
PD 3.0 with a maximum power delivery of 100W. Compatible with all DP Alt mode
supported Type-C hosts, this hub is the perfect companion for seamless connectivity
wherever you go. Say goodbye to limitations and hello to endless possibilities with the
Type-C 6-in-1 Hub.
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the packaging:
• Main Unit x1
• User Manual
Type-C Male X1 Host Computer
Upstream:
• Supports DP1.4 Alt mode
Downstream:
• Max 5Gbps data transmission
• Max 900mA downstream charging
• Supports short-circuit, over-current,
over-voltage protection
Type-C Data X1 (Close to HDMI)
• Supports max 100W PD charging , max
85W PD charging for PC (15w is
dedicated to the functioning of this
product)
• Supports PD3.0 Fast Role Swap, the
connected device will not get
disconnected while plugging in and out
PD Adapter
Type-C PD Charging X1
USB-A X2
• Max 5Gbps data transmission per port
• The port close to RJ45 supports max
5V/1.5A downstream charging, another
port supports max 900mA downstream
charging
• Supports short-circuit, over-current,
over-voltage protection
RJ45 X1
•
Supports Gigabit Ethernet,10M/100M/1000M
• Supports to work with Nintendo Switch
• Supports Wake-On-LAN
• Light indicates the state, no light when
no Internet connected, orange light
turns on when network connection is
established, green light ashes when
transmitting data
• Supports HDMI max 4k/60Hz
• Supports High Dynamic Range(HDR)
• Supports multiple color formats: RGB;
YCbCr4:4:4; YCbCr4:2:2; YCbCr4:2:0
8/10/12/16 bpc;
• Supports HPD
• Supports HDCP2.3 , HDCP2.2 and
HDCP1.4
HDMI X1
Package Contents
SpecicationIntroduction
Input/Output Connector
Power Supply
Warranty
Limited Warranty 3 Years
Physical
Weight 2.3lbs (66g)
Size 5.2x0.9x0.6in (134.3x22.9x16.8mm)
User Manual
Accessory Adapter
English Version
Certications
Regulatory Approvals
FCC, CE
Operating Temperature
Storage Humidity
Storage Temperature
Operating Humidity
0°C to 45°C (32°F to 104°F)
10% to 90 % RH (no condensation)
-10°C to 90°C (14°F to 158°F)
10% to 90% RH (no condensation)
Environmental
Operating Temperature
Input USB-C Male x1
Output HDMI p1-x1
Type-C Data x1
USB-A x2
RJ45 x1
Type-C PD Charging x1
USB-C PD Charging Port 100W(20V/5A)
®
Type-C to HDMI(4K/60Hz)/USB-Ax2/RJ45/USB-C Data
Type-C PD Charging with DP1.4 Alt mode
User Manual
Y10A311-S1
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Keep this manual for future reference.
