GN

GN

GN

GN

GND

D

D

D

D

PackageContents

1of1

AssemblyInstructionSheet#IS-PCGL8530BN

ForStylesPCGL8530BN

ThankyouforpurchasingaQuoizelproduct.

Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-631-273-2700

orvisituson-lineatwww.quoizel.com

2015QuoizelInc.

March2015

STEP1InstallInnerBackplateandFixtureBody-

A.PassthesupplywiresthroughInnerBackplate(A).AttachInner

Backplate(A)toOutletBoxwiththeheadofGreenGroundScrew

facingyou.SecureitwithOutletBoxScrews(notincluded).Tighten

untilsnug

B.RaceallsupplywiresthroughtheInnerBackplate(A)asshown.

RefertoStep2forwiringconnections.

C.AttachFixtureBody(E)overInnerBackplate(A)andsecurewith

LockScrews(B).Tightenuntilsnugwithscrewdrivers.

.

Whitewire

fromsupply

Whitewire

fromfixture

Blackwirefrom

supply(orRed)

Blackwire

fromfixture

Groundwire

fromsupply

Groundwire

fromfixture

Figure2

STEP3-InstallShades

A.PlaceGlass(D)intothe

FrameontheFixture

Body(E),lineupthe

holesontheGlass(D)

andthemountinghole

onthesecureby

threadingLockScrews

intothemountinghole.

Handtightenuntilsung.

Frame,

Yourfixtureisnow

assembledandready

touse.Enjoy!

Figure1

Outlet

Box

OutletBox

Screw

PackageContents

E

B

Mounting

Screw

x2

Inner

Backplate

x1

A

FixtureBody

x1

D

Glass

x1

STEP2-WireConnections

A.Usestandardwireconnectors(notincluded)tomakeallwire

connections.(Connectorsarenotincludedwithfixture.)Twist

connectorsuntilwiresaretightlyjoinedtogether.Wrapeach

connectionwithapprovedelectricaltapeandcarefullystuffallthe

connectedwiresbetweenInnerBackplate(A)andFixtureBody(D).

Figure4

Pleasegotoforproductcleaningtips.Gototheselection.www.quoizel.comCare+Maintenance

LightSource:

ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.

EstimatedAssemblyTime:

Preparation:

LED30W

20-30minutes

Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtobesureallpartsare

present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement

parts.

WarningsandCautions

Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.

Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly

recommendthatalicensed,professionalelectricianperformtheinstallation.

Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocoolbeforeremoval.Donotsubject

glasspartstoanyshockwhileinoperationorshatteringmayresult.

C

LockScrew

x4

A

B

E

D

C

E

PCGL8530BN

FINISH:BRUSHEDNICKEL

PARTNUMBER

NOTE:ALLDIMENSIONSAREROUNDEDUPTO

THENEAREST1/4"

REPLACEMENTPART

NO.

1

G4005SH

SHADE

REQ.

1

4.75”

1

5”5.5”

28.5”

6.75”

30”
