1of1

ForStyleLRY1720Y

WarningsandCautions

Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.

Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly

recommendthatalicensed,professionalelectricianperformtheinstallation.

Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocoolbeforeremoval.

Pleasegotoforproductcleaningtips.Gototheselection.

(3)B10CandelabraBasebulbs60WMaximum,bulbnotincluded.

30-45minutes

Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtoensureallpartsare

present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.MissingParts?Contactyouroriginalplaceof

purchase.

www.quoizel.comCare+Maintenance

LightSource:

EstimatedAssemblyTime:

Preparation:

ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.

InstallationGuide#IS-LRY1720Y

2018QuoizelInc.

visituson-lineatwww.quoizel.com

PackageContents

Figure2

GreenGroundScrew

ontheCrossbar

Whitewire

fromoutletbox

Whitewire

fromfixture

Blackwirefrom

outletbox(orRed)

Blackwire

fromfixture

Bare,orGreen

Groundwire

fromoutletbox

Groundwire

fromFixture

STEP2-WireConnections

A.

B.Usestandardwireconnectors(notincluded)tomakeallwire

connections.Twistconnectorsuntilwiresaretightlyjoinedtogether.

Wrapeachconnectionwithapprovedelectricaltapeandcarefully

stuffalltheconnectedwiresintotheOutletBox.

Wrapbareorgreengroundwirearoundgreengroundscrewonthe

crossbar,nolessthan2inchesfromtheendofthewire.Tightenthe

greengroundscrew.

FixtureBody

x1

C

B

Glass

x3

Crossbar

x1

Assembly

A

TopView

STEP1-InstalltheCrossbarAssemblytoOutletBoxandAdjust

thelengthoftheNipple

a.UnfoldsupportarmsonFixtureBody(C)toproperlocations.

b.AttachtheCrossbarAssembly(A)totheOutletBoxwiththeheadof

theGreenGroundScrewfacingyou.SecureitwithOutletBox

Screws(notincluded),tightenuntilsnug

c.Adjustthehexnutandlockwasherundersideofthecrossbartothe

middleofthenipple.

d.RemovethefromtheNipple.PlacetheFixtureCanopy

overtheNippleagainsttheceilingtodeterminethecorrectposition

ofthenipple.ThreadtheFinialontotheNipple.Adjustthenippleto

allowtheFixtureCanopytorestagainsttheceilingwhenheldin

placebythe.

e.RemovetheandtheFixtureCanopy.Tightenthelock

washeragainstthecrossbartosecureinplace.

.

LockBall

LockBall

LockBall

OutletBoxScrew

(notincluded)

HexNutand

LockWasher

OutletBox

GreenGroundScrew

A

LockBall

Nipple

FixtureCanopy

STEP3InstallFixtureBodytoCrossbar-

A.AttachtheFixtureBody(C)overtheendoftheNippleandsecure

withthe.Handtightenuntilsnug.

LockBall

Figure3

Nipple

LockBall

Crossbar

ReleasedDate:2019-01-08
