Sivu 1/6
Visit Our Website
SCAN ME
PyleUSA.com
USER GUIDE
Questions or Comments?
We are here to help!
Phone: 1.718.535.1800
PyleUSA.com/ContactUs
PLUTV40BTA
4” Waterproof Rated Off-Road
Wireless BT Streaming Speakers
www.PyleUSA.com2www.PyleUSA.com 3
READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT.
RETAIN THIS OWNER’S MANUAL FOR FUTURE REFERENCE.
Features:
• Pro Audio PowerSport Speakers
• Amplied (Active + Passive) Speaker System
• Bluetooth Wireless Music Streaming Ability
• Marine Grade Waterproof Rated Construction
• Weatherproof & Water-Resistant Housing
• 2-Way Full Range Stereo Sound Reproduction
• Built-in Digital Sound Processing Amplier
• Compact Size & High-Powered Output
• Impressive Bass Response
• Integrated Power & Wiring Harness
• Aux (3.5mm) Input Jack
• Connect & Stream Audio from External Devices
• Sleek Design, Machine Molded Speaker Cabinet Housing)
• Rugged, Universal Mount Bracket Design for Roll-Bar / Roll-Cage
• Built-Into Amplier of Main / Active Speaker
• Used for O-Road Outdoor Vehicles: ATV, UTV, 4x4, Jeeps, Marine Watercraft
• *Bluetooth Receiver Module
Bluetooth Wireless Streaming:
• Simple & Hassle-Free Pairing
• Instant Wireless Audio Streaming Ability
• Works with All of Today’s Latest Devices Smartphones, Tablets, Laptops, etc.
• Bluetooth Version: V5.0
• Bluetooth Network Name:‘PyleUSA’
• Wireless Range: 30+ ft.
WHAT’S IN THE BOX:
• (1) Active O-Road Speaker
• (1) Passive O-Road Speaker
• (1) 2.5M Speaker Wire Between Active and Passive Speakers
• (1) 3.5mm Stereo Cable
• (6) Rubber Pads 4.53'' x 1.18'' x 0.12'' -inches
Technical Specs:
• Speaker Power: 900 Watt MAX
• Amp Power: 2 x 450 Watt MAX @ 4 Ohms (2 x 225 Watt RMS)
• Power Supply: DC 12V
• Amp Type: 2-Channel, Class D
• Bridged Sound System: (2) x 4.0'' Woofers + (2) x 1'' Tweeters
• Marine Grade Waterproof Rating: IP-X5
• Speaker Type: Polypropylene Cone, Butyl Rubber Surround (x2)
• Tweeter Type: Neodymium Dome (x2)
• Frequency Response: 105Hz-20kHz
• Impedance: 4 Ohm
• Magnet Type: 30 oz. Circuit
• Mid-Woofer Voice Coil Type: 1.0'', KSV
• Sensitivity: 90 dB +/- 2 dB @ 1M/1W
• Anti-Thump Turn-On
• Soft Turn On/O
• T.H.D: <0.05%
• S/N Ratio: >70dB
• Channel Separation: >65dB
• Amp Freq. Response: 20Hz- 30kHz
• Fuse: 1 x 15A
• Universal Mounting Brackets Roll-Bar / Roll-Cage Diameter: 1.5” ~ 2.0” -inches
• Speaker Dimensions (L x W x H): 5.5” x 8.0” x 7.4” -inches, with Bracket (Each)
California Prop 65 Warning
WARNING:
This product contains Di (2-ethylhexyl) phthalate (DEHP) which
is known to the state of California to cause cancer birth
defects and other reproductive harm. Do not ingest.
For more info go to: www.P65warnings.ca.gov
www.PyleUSA.com4www.PyleUSA.com 5
INSTALLATION
Please Note:
The instructions below refer to the most common bar sizes: 1.5”, 1.75”, and 2”.
However, using the supplied rubber pads will allow you to mount these speakers
on any bar size measured between 1.5” and 2”.
WIRE DIAGRAM
12V Wire harness connection
Step 1
Remove Both
Screws
Remove the two screws from the
bracket to separate the speaker pod
and the bracket.
Step 2
The rubber pads will need to be cut to the
appropriate length so they t the speaker
pod and the bracket. After cutting the rubber
pads, remove the white protective layer and
stick them to the speaker pod and the
bracket.
Remove the backing from the pad and
wrap it around the bar.
Screw the two screws evenly until snug. Once
the position is veried, tighten the screws
another half-turn. DO NOT OVERTIGHTEN!
Step 4
Screws
Mounting Bracket
Mounting Bar
4.5” par
4.5” par
4.5” par
2” Bar
1.75” Bar
1.5” Bar
Step 3
* The pad should go all the way
around the bar. If the pad is too
long, cut the extra length.
2” Bar doesn’t require
padding.
AUX IN
RCA
INSERT
INSERT
SQUEEZE
DC12V(-) Grounded to
metal chassis, or directly to
negative polarity of battery.
Yellow +
Black -
Black -
Gray +
DC12V(+)
Extention power cable
with fuse holder
(not included)
A essory 12cc
volt switched
Red
Remote
turn on out
Blue
Register Product
Thank you for choosing PyleUSA. By registering your product,
you ensure that you receive the full benets of our exclusive
warranty and personalized customer support. Complete the
form to access expert support and to keep your PyleUSA
purchase in perfect condition.
Start Here
PyleUSA.com/pages/register
