Sivu 1/12
khind.com.my
model / 型号
VC8012
P/N: 40-51523-00
Instruction Manual Buku Panduan/说明指示书 /
Please read this manual carefully before operating this product. Keep this manual handy for further reference.
请在使用此产品前,详读此说明书。并将之收藏以作日后参考。
Sila baca buku panduan ini dengan teliti sebelum menggunakan produk ini. Simpanlah untuk rujukan masa depan.
Important / / 重要 Mustahak
This manual is also available online.
Vacuum Cleaner / / 吸尘机 Pembersih Vakum
Cleaning & Maintenance
1. Always unplug the power cord before performing any cleaning.
2. It is recommended to regularly clean the dust container.
3. Do not clean the appliance’s surface with metal sourcing pads as it may scratch the surface or cause electrical
shock. Use only a damp soft cloth to clean it.
4. Do not immerse the appliance into the water or other liquids when cleaning.
5. Do not use abrasive chemicals, cleaning solvents like petrol, thinner or benzene to clean the appliance.
1. This appliance is not attended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
2. Read the instruction manual carefully and follow the instruction closely.
3. Use only the attached parts which are supplied by the manufacturer.
4. This appliance is intended for household use only. Commercial use will void warranty.
5. Do not leave the spplisnce unantended while it is connected to the main power outlet.
6. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied
persons in order to avoid any hazards.
7. Do not pull, lift or carry the appliance by its supply cord. In order to avoid damages to the cord, do not pull the
cord around sharp corners and edged.
8. Always switch o the power before unplugging the unit from the socket. Do not unplug by pulling and jerking
the cord with force.
9. Do not handle the plug or the aplliance with wet hands.
10. Do not vacuum the following corrosive or inammable liquids, lighted cigarette butts, ash or matches sharp
objecs or objects which could block and get stuck in the hose.
11. Do be more cautions when you want to clean and vacuum the staircase.
12. Make sure the household voltage is the same as that indicated on the rating label of the unit.
13. Do not use appliance without the lters.
14. Hold the plug when rewinding onto the cord reel. Do not allow the plug to whip when rewinding.
15. Do not wrest, tramp and haul the hose.
16. Keep the appliance away from the ovens and stoves etc.
17. Kept the appliance dry to protect agains electric shock.
1 2
Safety Precaution Information
!
Safety & Warning Information
Parts Identication
1. Performance Floor Brush
2. Metal Tube
3. Airow Regulator
4. Hose Handle
5. Hose
6. Dust Container Handle
7. Hose Connector
8. Wheel
9. Dust Container
10. Caster Wheel
11. Crevice Nozzle
12. ON/OFF Power Button
13. Tube Holder
14. Air Outlet
15. Dust Container Release Button
16. Cord Rewinder Button
17. Dust Container Top Cover
18. Sponge Filter
19. Cyclone Unit
* Pictures are for illustration purpose only.
17
18
19
16
12
14
13
11
15
1
2
3
4
5
8
9
10
6
7
3
4
Specications
How to Use
2. Pull out the power cord to its full length and plug it into the power supply.
3. Switch on the power supply and press the On/O power button to start operating the vacuum cleaner.
4. Before rewinding the power cord, unplug from the power supply and press the cord rewinder button.
Always hold the plug before pressing the cord rewinder button as the cord will retract very quickly.
NOTE: In case of long operation time, it is recommended that after every 30 minutes of usage, a short interval
rest is taken.
a. Connect the hose handle to the main nozzle or
crevice nozzle together with metal tube.
b. Insert the hose connector to the vacuum body.
* Specications are subject to change without prior notice.
Model
Voltage
Power
Suction Power
Cable Length
Noise Level
Air Flow
Dust Container Capacity
Filtration Type
Net Weight
Product Dimension (LxWxH)mm
:
:
:
:
:
:
:
:
:
:
:
VC8012
220-240V ~ 50/60Hz
1200W
140W; 20kPa
4.5 meter
84dB
1.5m /min
2L
Multi Cyclone
3.8kg
330 x 238 x 285mm
3
A ASSEMBLE THE UNITS
1. Remove and assemble the hose connector, hose, metal tube, main nozzle or crevice nozzle from the box.
B CLEAN THE DUST CONTAINER & FILTER
1. The dust container should be emptied regularly to obtain consistent best results.
2. Switch o and unplug before disengage the dust container by pressing the dust container release button on
the handle.
3. Press the button and lift the container away from vacuum body.
4. Clear the dust from the container before cleaning.
5. Remove the Dust Container Top Cover, Sponge Filter & Cyclone Unit from Dust Container.
6. Tap the Sponge Filter against the side of a dustbin softly and clean it with a soft brush to remove excess dust.
7. Wash the Dust Container and Sponge Filter with warm or cold water if necessary.
8. Do not use detergents to clean the Dust Container and Sponge Filter.
9. Make sure the Dust Container and Sponge Filter is completely dry before install back to main body.
10. Do not expose the Sponge Filter under the sun to avoid any damage.
C CARRYING THE APPLIANCE
1. Carry the appliance by the dust container handle on the body.
2. Do not press the dust container release button or shake the appliance when carrying, otherwise the dust
container could disengage, fall o and cause injuries.
清洁和维护
1. 在进行任何清洁之前，请务必拔掉电源线。
2. 建议定期清洁集尘桶。
3. 请勿使用金属源垫清洁设备表面，否则可能会划伤表面或导致触电。只能使用潮湿的软布清洁它。
4. 清洁时请勿将产品浸入水中或其他液体中。
5. 请勿使用腐蚀性化学品、汽油、稀释剂或苯等清洁溶剂来清洁设备。
安全预防措施
!
安全和警告信息
1. 本设备不适合身体、感官或精神上有障疑或缺乏经验和知识的人（包括儿童）使用，除非他们已由负
责他们的人员对设备的使用进行监督或指导安全。
应监督儿童以确保他们不会玩弄本设备。
2. 仔细阅读使用说明书，并严格按照说明进行操作。
3. 仅使用制造商提供的附件。
4. 本设备仅供家庭使用。商业用途将使保修失效。
5. 当设备连接到主电源插座时，请勿让设备无人看管。
6. 如果电源线损坏，必须由制造商、其服务代理或具有类似资格的人员更换，以免发生任何危险。
7. 请勿通过电源线拉动、提升或搬运设备。为避免损坏电源线，请勿将电源线拉到尖角和边缘。
8. 从插座上拔下设备之前，请务必关闭电源。请勿用力拉扯和猛拉电源线来拔下插头。
9. 请勿用湿手处理插头或设备。
10. 请勿用吸尘器吸尘以下腐蚀性或易燃液体、点燃的烟头、灰烬或火柴等尖锐物体或可能阻塞和卡在软管
中的物体。
11. 对楼梯进行清洁和吸尘时要更加小心。
12. 确保家用电压与设备铭牌上的电压相同。
13. 不要使用没有过滤器的电器。
14. 绕到卷线器上时握住插头。倒带时不要让插头晃动。
15. 不要扭动、踩踏和拖拉软管。
16. 让电器远离烤箱和火炉等。
17. 保持设备干燥以防止触电。
