Sivu 1/26
Wet & Dry Vacuum Cleaner / /干湿两用吸尘机
Pembersih Vakum Basah & Kering
khind.com.my
model / 型号
VC3622
Instruction Manual / / 说明指示书 Buku Panduan
Please read this manual carefully before operating this product. Keep this manual handy for further reference.
请在使用此产品前,详读此说明书。并将之收藏以作日后参考。
Sila baca buku panduan ini dengan teliti sebelum menggunakan produk ini. Simpanlah untuk rujukan masa depan.
Important / / 重要 Mustahak
P/N: 40-51556-00
This manual is also available online.
1 2
Safety Precaution Information
!
1. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children shall not play with the appliance.
2. Read the instruction manual carefully and follow the instruction closely.
3. Make sure the household voltage is the same as that indicated on the rating label of the unit.
4. Always switch o, unplug from the socket after use or before cleaning the appliance or any maintenance
task.
5. Do not unplug by pulling and jerking the cord with force.
6. Do not handle the plug or the appliance with wet hands.
7. Use only the attached parts which are supplied by the manufacturer.
8. This appliance is intended for household use only. Do not use the appliance at any outdoor area.
Commercial use will void warranty.
9. Do not leave the appliance unattended while it is connected to the main power outlet.
10. Do not reverse the vacuum cleaner which may cause damage to the motor.
11. The hose cannot be overly bent and forced to elongate, otherwise the hose will be deformed or damaged.
12. Do not allow the lid part to penetrate into the water or rinse with water to prevent water from entering the
electronic parts. Leakage, proper operation: gently wipe the surface with a rag.
13. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualied persons in order to avoid any hazard.
14. Do not step on or wrap the cord around arms or legs when using the appliance.
15. Do not pull, lift or carry the appliance by its supply cord. In order to avoid damages to the cord, do not pull
the cord around sharp corners and edges.
16. Keep appliance away from the ovens and stoves etc.
17. Do not position the appliance above you when cleaning the stairs.
18. Do not use the appliance in a damp room.
19. Do not inhale hot dust ashes or sharp objects.
20. Do not point at anyone when blowing.
21. Do not inhale ammable, toxic liquids, such as gasoline, oil, acids or other volatile substances, to avoid
dangerous hazards. Do not immerse the appliance into the water or other liquids.
22. Always check whether the oat is normal.
23. Kept the appliance dry to protect against electric shock.
24. Do not use the air outlet directly against people or animals when using this product.
25. Liquid or steam must not be directed towards equipment containing electrical components, such as
ovens.
1. After cleaning the Dust Container, lters and related accessories, check if it leaks. After each use, clean the
lter and make sure you use the correct lter for dry and wet vacuum.
2. Check the plug if damaged.
3. Clean the Suction Port to make sure there is no blockage.
4. Handle the vacuum cleaner with care and do not drop or hit any solid object.
5. Keep the vacuum cleaner dry.
6. Clean the lter with cold water if needed, and if necessary, you may also use neutral detergent cleaning, do
not use corrosive objects to clean it. Do not put the entire lter into the water.
7. Do not let the vacuum work for a long time, each working time is best within 1 hour, otherwise will
reduce the vacuum lifespan.
8. Dust and debris on the lter will weaken the suction. Clean the lter more frequent to maintain best
performance.
9. If there is any abnormal vibration or noise or smell, you must stop the operation immediately, and proceed
with maintenance.
Safety & Warning Information
Safety Precaution Information
!
Cleaning & Maintenance
Filter Cleaning
1. Periodically check the lter to maintain performance.
2. If the suction performs on very tiny dust, the lter may need more frequent cleaning.
3. Wash the lters with cold or warm water without the use of detergent. (Fig 1 & 2)
4. Keep the cleaned parts in a wide area to dry. Advise to dry it for at least 24 hours.
Do not put the lter in a dishwasher, washing machine, roller dryer, oven, microwave oven or open ame.
(Fig 3)
Model VC3622
Voltage 220-240V ~ 50/60Hz
Power 600W
Dust Container Capacity 6L
Filtration Type Cartridge Filter
Power Cord Length 5m
Noise Level 82dB
Vacuum Pressure 15kPa
Net Weight 2.7kg
Product Dimension (LxWxH) 290 x 220 x 270mm
Parts Identication
* Pictures are for illustration purpose only.
1. On “ “ / O “ “ Switch
2. Top Cover
3. Suction Port
4. Dust Container
5. Dust Container Release Buckles
6. Handle
7. Hose
8. Crevice Nozzle
9. Flat Nozzle
10. Cartridge Filter for Dry Vacuuming
11. Sponge Filter for Wet Vacuuming
3
4
Specications
* Specications are subject to change without prior notice.
A] Product Installation
CAUTION: Make sure that the power cord plug and socket are de-energized when assembling the
vacuum cleaner.
1. Make sure the power cord is disconnected from the socket.
2. Flip up the Dust Container Release Buckles on both sides of the Dust Container lid with both hands at the
same time, lift the Top Cover upwards to separate it from the Dust Container.
3. Raise the Top Cover from Dust Container.
4. Take out all accessories from the packing box and Dust Container.
5. Put the hose on the Dust Container that already has the lter assembly, and press it down until the Dust
Container Release Buckles on both sides are locked.
6. Align the hose port with the suction port, and then rotate it to the right and insert it.
7. Connect the nozzle you need with the handle of the hose.
How to Use
1
6
5
2
3
4
7
8 9 10 11
