UC-PD2
UC-PD2
Recommended batteries : IDX V-Mount Lithium Ion batteries equipped with USB PD
Input voltage：AC100V〜240V 50 / 60Hz Automatic
Output voltage：
USB-C port：
DC5V/3A、DC9V/3A、DC12V/3A、DC15V/3A、DC20V/5A（ ）MAX100W
USB-A port： Single port ： DC5V/3A、DC9V/2A、DC12V/1.5A
Dual port ： DC5V/2A + DC5V/2A
DC Connector : USB Type-C 2port / USB Type-A 2port
Operating temperature ：0 / 3 〜25˚C 2 〜 77˚F
Operating humidity：5％〜80％ RH
Protection circuit : Over-voltage, Over-current, Short circuit
Dimensions：approx. 69 ( W ) × 87 ( H ) × 32 ( D )mm
approx. 2.71 ( W ) × 3.42 ( H ) × 1.26 ( D ) inches
The attached USB Type-C cable 5A length : approx. 1.5m approx. 59inches
Weight : approx. 290g / 0.64lbs
Charge time standard：For the latest charging time information, please visit our website
( https://idxtek.com/pages/charging-times )
IDX Lithium-ion batteries equipped with USB PD can be charged.
Equipped with two USB-C ports, supporting USB PD standards up to
100W single port and up to 65W dual port.The output voltage is
automatically switched by connecting the battery.The maximum output
when charging the battery depends on the USB PD input
specifications on the battery side.
Equipped with two USB-A ports, it can supply up to 18W single port
and up to 10W dual port at the same time.It can be used for portable
devices powered by USB
AC plug can be folded and stored.
POWER LED lights when connecting the AC plug to the outlet.
1. Connect the AC plug to the outlet.
Waring : Use in a flat surface only.
* The shape of the AC plugs varies by region
2. Connect the supplied USB Type-C cable
into the USB-C port on the charger and
the USB-C port on the IDX battery to start charging.
Confirm the IDX battery LED indicator is lit up when charging.
3. Remove the connector after charging.
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
①
②
④
③
⑤
●
●
●
●
●
●
●
●
●
●
Do not connect to an AC power source that exceeds the voltage
specification stated on the unit.
Use only with the compatible batteries listed in this manual.
Do not sho t the contact pins with any metal object. r
Do not ca y or store with metal equipment.rr
Do not immerse in water.
Do not attempt to open he outer casing or break apart.t
Do not subject the unit to extreme physical impact or pressure, or
place any object across the terminals that could cause it to short.
Do not a tempt to use if damaged.t
Protect the power cord from any damage.
Please don’t use the charger which has damages on the cable
and connector is deformed.
●
●
●
●
●
●
●
Use the approved power cord / appliance connector / plug
conforming to the proper ratings (voltage, ampere) and safety
regulations of each country if applicable.
Keep the unit away form excessively d y hot or humid environments.r
Stop charging immediately if the charging does not complete
within the designated time.
In case of abnormal smell , leak , color change or case deformity
during use, turn the power off and unplug the cable from the socket
to avoid possible injury .
Do not carry the charger while the battery is attached.
Do not charge the battery while the battery is used with equipments.
Do not charge the battery while the battery is charged from
other charger.
Operating Instructions
① Body
② Power LED
③ USB-A connector ×2
④ USB-C connector ×2
⑤ AC plug
● ● for EU for UK
● for US
* The shape of the AC plugs varies by region
Features Specifications
Location and Function of Parts
UC-PD2
2ch USB Power Delivery Charger
Instruction Manual
Thank you for purchasing the UC-PD2. This UC-PD2 is the charger which supports USB PD (Power Delivery)
function. We strongly recommend reading this Instruction Manual on how to best use the UC-PD2 . Please keep
this manual for your reference. If you have any additional questions, please contact your local IDX office listed
at the end of this manual.
UC-PD2
UC-PD2
