Sivu 1/14
APR-5112 EN ENGLISH-
INSTRUCTION MANUAL
1. SPEAKER
2. HANDLE
3. TUNING KNOB
4. -VOLUME +/
5. EARPHONE JACK
6. METAL ANTENNA
7. AC SOCKET
8. OFF/FM/AM
9. BATTERY COMPARTMENT
AC POWER SUPPLY
1. PLUGING THE AC CORD INTO THE AC SOCKET (7), CONNECT THE AC
POWER CORD TO YOUR AC HOUSEHOLD MAINS OUTLET. MAKE
SURE THE VOLTAGE IS COMPATIBLE.
2. DISCONNECT THE POWER CORD FROM THE MAINS WHEN NOT IN USE.
3. MAINS PLUG IS USED AS THE DISCONNECT DEVICE. IT SHALL REMAIN
READILY OPERABLE AND SHOULD NOT BE OBSTRUCTED DURING
INTENDED USE. TO BE COMPLETELY DISCONNECTED THE
APPARATUS FROM SUPPLY MAINS, THE MAIN PLUG OF THE
APPARATUS SHALL BE DISCONNECTED FROM THE MAINS SOCKET
OUTLET COMPLETELY.
BATTERY OPERATION
1. THE UNIT CAN ALSO BE OPERATED BY BATTERIES DURING POWER
FAILURE.
2. OPEN THE BATTERY COMPARTMENT (9), AND INSTALL 4PCS 1.5-VOLT
AA BATTERIES.
3. REMOVE BATTERIES FORM THE UNIT IF NOT BE USED FOR SOME
TIME.
4. FLAT BATTERIES SHOULD BE REMOVED FROM THE COMPARTMEN
T
AVOID LEAKAGE.
5. BATTERIES SHALL NOT BE EXPOSED TO EXCESSIVE HEAT SUCH AS
SUNSHINE, FIRE OR LIKE.
RADIO OPERATION
ROTATE (4VOLUME KNOB ) TO TURN ON THE RADIO, ROTATE THE TUNING
KNOB (3) TO ADJUST YOUR DESIRED FREQUENCY. ROTATE VOLUME
KNOB (4) TO INCREASE / DECREASE THE VOLUME.
SLIDE THE BAND SELECTOR (8) TO YOUR FAVOURITE BAND (FM/AM), AND
ROTATE THE TURNING KNOB TO TUNE TO THE RADIO STATION YOU LIKE.
EARPHONE JACK
FOR HEADPHONE OPERATION, USE A HEADPHONE SET WITH 3.5MM
STEREO JACK PLUG PLUGGED INTO THE PHONE JACK (EAR 5 ).
SPECIFICATIONS:
FREQUENCY: FM 87.5 – 108 MHz
AM 522- 2 16 0 KHz
POWER SUPPLY: - AC 220 240V~ 50Hz 5W
DC AA x 4
(BATTERIES NOT INCLUDED)
IMPORTANT SAFETY INSTRUCTIONS
1. CAUTION: These servicing instructions are for use by qualified service
personnel only. To reduce the risk of electric shock, do not perform any
servicing other than that contained in the operating instructions unless you
are qualified to do so.
2. Do not install this equipment in a confined or building-in space such as a
book case or similar unit, and remain a well ventilation conditions at open
site. The ventilation should not be impeded by covering the ventilation
openings with items such as newspaper, table-cloths, curtains etc.
3. WARNING: Only use attachments/accessories specified or provided by the
manufacturer (such as the exclusive supply adapter, battery etc).
4. WARNINGPlease refer the information on exterior bottom enclosure for
electrical and safety beforeinformation installing or operating the apparatus.
5. WARNINGTo reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture. The apparatus shall not be exposed to dripping
or splashing and that objects filled with liquids, such as vases, shall not be
placed on apparatus.
6. WARNING: The batteries (battery pack or batteries installed) shall not be
exposed to excessive heat such as sunshine, fire or the like.
7. WARNING: Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type.
8. WARNING: Please refer the information on exterior bottom enclosure for
electrical and safety information before installing or operating the apparatus.
9. WARNING: The mains plug is used as disconnect deice, the disconnect
device shall remain readily operable.
