Sivu 1/7
BLUETOOTH SPEAKER
WITH TOUCH BUTTON
INSTRUCTION MANUAL
Thank you for selecting and buying V-TAC Product. V-TAC will serve you the best. Please
read these instructions carefully & keep this user manual handy for future reference. If
you have any another query, please contact our dealer or local vendor from whom you
have purchased the product. They are trained and ready to serve you at the best.
INTRODUCTION & WARRANTY
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
MODEL : VT-6133
SKU : 7725, 7726
GETTING STARTED
FEATURES
SPECIFICATIONS
PACKAGE CONTENTS NOTE
• Bluetooth Speaker (1pc)
• USB Cable (1pc)
• Auxiliary cable (1pc)
• Instruction Manual (1pc)
• Bluetooth® Version: 5.0
• Wireless Streaming Range Distance: 10 meter
• Speaker output: 5W
• Unit Size:120x60x230 mm
• Power Input: DC 5V
• Built-In Rechargeable Battery: 3.7V /
1200mAh
• So Touch Buttons for Smooth Operation with Blue light.
• Supports TWS function for better sound eect.
• Compatible with wireless products featuring Bluetooth® technology
• AUX Input Function
• Supports TF Card
• Built-in Mic for Hands Free Calls
• With FM Radio Function
• Micro USB charging cable included
• Operation distance: Up to 10 meters
SAFETY INSTRUCTIONS
• Read these instructions carefully.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings.
• Do not use near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
• Protect the power cord from being walked on or pinched particularly at plugs.
• Only use atachments/accessories specified by the manufacturer.
• Unplug this apparatus during lightning storms or when unused for long periods of time.
• Remove the speaker from the box.
• Please retain all packaging until aer you
have checked and counted all the parts
and the contents against the Package
Contents list.
• Radio frequency band: 2.048G-2.480G
• Radio-frequency power transmitted: 6dB
This marking indicates that this
product should not be disposed
of with other household wastes.
ENGLISH
DESCRIPTION OF PARTS
CHARGING THE SPEAKER
TURNING ON/OFF THE SPEAKER
TWS FUNCTION
The speaker has built-in rechargeable battery. When the battery is drained out, speaker would turn OFF
automatically. Please recharge the battery every time it drains out.
Plug the Micro USB end of the included USB charging cable into the charging port.
Plug the other end into a USB port on your computer or other devices made for USB charging. Red LED
Light illuminates indicating that the device is being charged.
It takes 3 - 4 hours to fully charge the speaker. Once the speaker is fully charged, LED Light would turn
OFF.
It is recommended to fully charge the speaker before its first use.
Before Turning ON the speaker, please ensure that it is fully charged.
Press ON/OFF button to turn the device ON/OFF.
It is possible to use two copies of this speaker, paired together, to benefit from a stereo sound.
To do this, turn on both speakers, then press the M button on one of them once.
The two speaker will connect to each other.
You can then pair your device with the stereo unit by following the procedure below.
Ensure that both speakers are spaced less than 10 meters
1. LED indicator
2. Mode/TWS button
3. Skip Backward /Volume Decrease - Button
4. ON/OFF/ Play/Pause/Phone Button
5. Skip Forward /Volume Increase + Button
6. ON/OFF button
7. Micro SD (TF) Card Slot
8. Charging Port
9. Auxiliary port
1 2 3 4 5 6 76 8
