POWER AND CONNECT

1

GET ONLINE

2

NEED MORE HELP?

1. Support forum: http://support.teradek.com → Contains tips, information and all the latest firmware & software updates.

2. Training videos: http://www.teradek.com/training

TERADEK SUPPORT STAFF: support@teradek.com or call 888−941−2111 ext2 (Mon−Fri 9am to 6pm PST)

A: SD card slot

B: Video input status

C: Encoder status

D: Broadcast status

E: Warning indicator

F: Start/Stop joystick

G: Menu joystick

H: USB port

I: HDMI input

J: MIC/Line input

K: Headphone output

L: Reset button

M: 10/100/1000 Ethernet

N: Power input

O: Power switch

pantone 1795pantone 355pantone 307

F

G

A

J

K

L

M

N

O

B

D

E

C

I

H

Start/Stop Joystick:

●(button press): Start/stop broadcasts, exit menu screens

▲

▲

▲

ANDROID/PC

The VidiU iOS app allows you to remotely monitor and configure VidiU Pro. Download the VidiU iOS

app from the App Store, then choose one of the following methods to get VidiU online.

Connect your device to VidiU Pro’s AP network: VidiU−Pro−XXXXX.

Insert a compatible 3G/4G USB modem into the USB port and wait for the icon to appear.

See http://support.teradek.com for a list of supported modems.

Connect your iOS device to VidiU Pro’s AP network: VidiU-Pro-XXXXX.

Open the VidiU app and select the corresponding VidiU Pro.

From the VidiU app, tap the Settings button, select Network, then select Wireless.

When prompted, click Yes to use your cellular data plan. If you have a ShareLink account, up to four

phones can be used simultaneously.

To connect to a different network, select Client, then tap Scan for Networks.

1

2

1

1

3

2

2

3

3

4

5

Teradek regularly releases new firmware versions to improve performance, add new features, or to fix vulnerabilities.

Visit https://www.teradek.com to update your device with the latest firmware.

CONNECT VIA WIFI

CONNECT VIA ETHERNET

4

Select a network, then connect your iOS device to that network.

USE YOUR PHONE’S DATA PLAN

Connect your iOS device to VidiU Pro’s AP network: VidiU-Pro-XXXXX (XXXXX is the last five

digits of the device’s serial number).

CONNECT VIA A 3G/4G USB MODEM

Menu Joystick:

▲,▼, , : Select menu items, change status screen on main display, select characters

,●(button press): Confirm selection, open selected menu

Reset Button:

Hold for 3−6 seconds: Reset all network settings

Hold for 10+ seconds: Perform complete factory reset

Connect power to Cube using the included A/C adapter or one of the available accessory

power cables (see Teradek.com).

Connect the HDMI output from your video source to VidiU Pro’s HDMI input connector (I).

1

2

Open a web browser and navigate to http://172.16.1.1.

From the VidiU web UI, tap the Settings button, select Network, open the WiFi menu, then tap Modify.

To connect to a different network, select Client, then tapBrowse to scan for networks.

Select a network, then connect your device to that network.

Plug an Ethernet cable into VidiU Pro’s 10/100/1000 Ethernet port and connect it to an Ethernet switch

or router. From the web UI, VidiU app, or front panel interface, navigate to the Network Setup menu, then

select Wired to verify that Ethernet is set to DHCP and to view VidiU Pro’s IP address.

iOS
