Kon-Tiki

Tech Handbook

Swift Group

Dunswell Road

Cottingham

East Yorkshire HU16 4JX

Tel 01482 875740

Fax 01482 840082

email enquiry@swiftgroup.co.uk

For more information visit

www.swiftgroup.co.uk

Issued July 2012

1401051

Contents

Standard Speciﬁcations ............................................................. 2

Optional Speciﬁcations .............................................................. 4

Capacities ................................................................................. 10

Towing Capabilities .................................................................. 12

Jacking ..................................................................................... 14

Wiring Diagrams ....................................................................... 15

Bulb Chart ................................................................................. 21

Bulb Replacement ...................................................................... 22

2 3

Standard Speciﬁcations 2.3L Manual

NOTE: 1. The Maximum User Payload includes:

a) the conventional load (this is the allowance for

passengers)

b) essential habitation equipment (items and

ﬂuids required for safe and proper functioning of

habitation equipment)

c) optional equipment (items available from

the manufacturer over and above the standard

speciﬁcation)

d) personal effects (those items not covered by

the above)

2. The Mass in Running Order is the mass of the

unladen vehicle including a 75kg allowance for the

driver plus engine coolants and 90% of the fuel tank,

water tank and gas capacity.

3. PLEASE TAKE CARE TO ENSURE THAT YOU HAVE

ALLOWED FOR THE MASSES OF ALL ITEMS YOU

INTEND TO CARRY IN THE MOTOR CARAVAN,

e.g. passengers, optional equipment, essential

habitation equipment and personal effects, such

as clothing, food, pets, bicycles, sailboards, sports

equipment etc.

4. WARNING - UNDER NO CIRCUMSTANCES

SHOULD THE MAXIMUM TECHNICAL PERMISSIBLE

LADEN MASS OF THIS MOTOR CARAVAN BE

EXCEEDED.

* Add 120mm to length if ladder option ﬁtted.

** Add 100mm to height on low line if ladder

option ﬁtted.

Model Kon-Tiki 659 Kon-Tiki 669 Kon-Tiki 669 Kon-Tiki 679 Kon-Tiki 679 Kon-Tiki 649

Roof Proﬁle Low Line Low Line High Line Low Line High Line High Line

Engine 150 MJT 150 MJT 150 MJT 150 MJT 150 MJT 150 MJT

Engine Capacity 2287cc 2287cc 2287cc 2287cc 2287cc 2287cc

Max Power 109kW @ 3600rpm 109kW @ 3600rpm 109kW @ 3600rpm 109kW @ 3600rpm 109kW @ 3600rpm 109kW @ 3600rpm

Torque 350Nm @ 1500rpm 350Nm @ 1500rpm 350Nm @ 1500rpm 350Nm @ 1500rpm 350Nm @ 1500rpm 350Nm @ 1500rpm

Chassis Fiat AL-KO low line Fiat AL-KO low line Fiat AL-KO low line Fiat AL-KO low line Fiat AL-KO low line Fiat AL-KO low line

Wheel base

4.60m /15' 1"- 0.80m/2' 7" 4.60m /15' 1"- 0.80m/2' 7" 4.60m /15' 1"- 0.80m/2' 7" 4.60m /15' 1"- 0.80m/2' 7" 4.60m /15' 1"- 0.80m/2' 7" 4.60m /15' 1"- 0.80m/2' 7"

Designated Passenger Seats 3 3 3 3 3 5

Berths (sleeping positions) 4 4 6 4 6 6

Overall Length * 8.56m/ 28' 1" 8.56m/ 28' 1" 8.56m/ 28' 1" 8.56m/ 28' 1" 8.56m/ 28' 1" 8.56m/ 28' 1"

Overall Width (mirrors folded) 2.35m/ 7' 8" 2.35m/ 7' 8" 2.35m/ 7' 8" 2.35m/ 7' 8" 2.35m/ 7' 8" 2.35m/ 7' 8"

Overall Height** 2.98m/ 9' 9" 2.98m/ 9' 9" 3.08m/ 10' 1" 2.98m/ 9' 9" 3.08m/ 10' 1" 3.08m/ 10' 1"

Maximum Technical Permissible Laden

Mass (A)

5000kg 5000kg 5000kg 5000kg 5000kg 5000kg

Mass in Running Order (B)† 4135kg 4230kg 4290kg 4230kg 4290kg 4295kg

Maximum User Payload (A-B) 865kg 770kg 710kg 770kg 710kg 705kg

Unladen Weight 3816kg 3911kg 3971kg 3911kg 3971kg 3976kg

Essential Habitation Equipment 9kg 9kg 9kg 9kg 9kg 9kg

Thermal Insulation Grade THREE THREE THREE THREE THREE THREE

Bed Sizes

Front Double 2.12m x 1.38m/ 6'11" x 4'6" 2.08m x 1.38m/ 6'10" x 4'6" 2.08m x 1.38m/ 6'10" x 4'6" 2.08m x 1.38m/ 6'10" x 4'6" 2.08m x 1.38m/ 6'10" x 4'6" 2.12m x 1.38m/ 7'0" x 4'6"

Front Offside Single

Rear Double 1.92m x 1.36m/ 6'4" x 4'6" 1.86m x 1.30m/ 6'1" x 4'3" 1.86m x 1.30m/ 6'1" x 4'3" 2.04m x 1.30m/ 6'8" x 4'3" 2.04m x 1.30m/ 6'8" x 4'3" 2.08m x 1.39m/ 6'10" x 4'7"

Rear Offside Single 1.86m x 0.70m/ 6'1" x 2'4"

Rear Nearside Single 1.88m x 0.70m/ 6'2" x 2'5"

Overcab Bed 1.91m x 1.37m/ 6'3" x 4'6" 1.91m x 1.37m/ 6'3" x 4'6" 1.91m x 1.37m/ 6'3" x 4'6"
