Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: July 18, 2019 12:19 PM

Product Diagram (SSPMSUDWM)

ComponentFunction

1

Docking Station

Mount

• Used to mount a StarTech.com Docking

StationHub or to a desk or wall.

2Mounting Holes

• Used to mount the to Docking Station Mount

a desk or wall.

3

Docking Station

Mounting Holes

• Used to mount a StarTech.com Docking

StationHubDocking Station or to the

Mount.

Requirements

For the latest requirements, please visit www.startech.com/SSPMSUDWM

• Robertson Head Screwdriver x 1

Package Contents

• Docking Station Mount x 1

• M3 x 5 mm Screws x 4

• #5-20 x 5/8” Wood Screws x 4

• Quick-Start Guide x 1

Mount for StarTech.com Docking Stations and Hubs

Attaching a StarTech.com Docking Station or Hub

1. Align the on the with the on the Mounting HolesAdapterMounting Holes

StarTech.com Docking StationHub or . The recessed hole pattern should be facing

outward so the will t properly.M3 x 5 mm (Countersunk) Screws

2. Insert the four through the on the M3 x 5 mm ScrewsMounting HolesAdapter

and into the on the or .Mounting HolesStartech.com Docking StationHub

3. Using a (sold separately) tighten the , Phillips Head ScrewdriverM3 x 5 mm Screws

being careful not to over-tighten the .M3 x 5 mm Screws

Mounting the Docking Station Mount on a Desk

Note: Make sure that the thickness of the Desk is greater than 12.5 mm (.5”) to ensure

that the screws do not penetrate the opposite side of the desk.

1. Align the on the desk.Docking Station Mount

2. Insert the # in the on the 5-20 x 5/8” Wood ScrewsMounting HolesDocking

Station Mount.

3. Using a (sold separately), tighten the #Robertson Head Screwdriver 5-20 x 5/8”

Wood Screws.

Mounting the Docking Station Mount on a Wall

Notes: It is recommended to use wall studs when mounting the Docking Station

Mount onto a Wall.

You may need to drill pilot holes when mounting the into a Docking Station Mount

wall stud.

1. Align the on the .Docking Station MountWall

2. Insert the # in the on the 5-20 x 5/8” Wood ScrewsMounting HolesDocking

Station Mount.

3. Using a , tighten the #.Robertson Head Screwdriver5-20 x 5/8” Wood Screws

2

1

3
