Quick-Start Guide

Product ID

H2MPV-MONITOR-MOUNT

Dual Monitor Desk Mount - Single Heavy-Duty Pole - Up to 49” 32:9 Monitors

FeatureFunction

1VESA Plate

• Use to mount a onto the MonitorMonitor Mount

• Features a design for mounting and Quick-Release

unmounting of the Monitor

2Monitor Mount• Secures the along the MonitorPole

3Pole Cap

• Enables to pass-through into the CablesPole

• Composed of two halves that are press tted onto the Pole

4Support Collar

• Supports the weight of the while adjusting the Monitor

Monitor MountPole around the

• secure it into place Set Screws

Note: The Support Collar is not meant to solely support the

Monitor weight

5Monitor Mount Lever• Use to tighten or loosen the Monitor Mount

6Cable Pass-Through Hole• Route cables through the for PoleCable Management

7Pole Assembly

• Enables to vary the height of the Monitors

• A single assembly composed of the and PoleDesk Clamp,

Upper

8Desk Clamp, Lower

• Secures the to a desk or tableMonitor Desk Mount

• Adjustable height to match the thickness of the desk or table

• Supported thickness range of 1to 3.9-inch (25 to 100mm)

Package Contents

• Desk Clamp, Lower () x 1A

• Pole Assembly () x 1B

• Pole Cap () x 1C

• Monitor Mount () x 2D

• VESA Plate () x 2E

• Support Collar () x 2F

• M4x10mm Screws ()x 8G

• M4x16mm Screws() x 8H

• 3/8” x 1/2” Screws () x 2I

• Spacers () x 8J

• M6 Hex Key () x 1K

• M3 Hex Key () x 1L

• Wrench () x 1M

*Product may vary from image

1

8

3

5

2

6

2

6

7

1

4

5

4
