Quick-Start Guide

Manual Revision: March 18, 2024

For additional self-service support options and community forums, please visit: www.StarTech.com/support

Product ID

DOCK-NUC-VESA-MOUNT

ComponentFunction

1

Device VESA

Mounting Points

• VESA Compatible75x75mm100x100mm and

• Use to mount a , , or other NUCThin ClientComputer

VESA Compatible accessories

2Mounting Slots

• Use to mount StarTech.com , Docking StationsThin

ClientComputerVESA Compatible , or other accessories

Note: Other non-StarTech.com Docking Stations may be

compatible if they have a 40x40mm Mounting Pattern

• are spaced 40mm between each LongMounting Slots

other. Use to mount Docking Stations

• are spaced 54.7mm vertically and Short Mounting Slots

horizontally. Use to mount a or other compatible NUC

Thin Client VESA Mount Bracketcomputerwithout a

3

Monitor VESA

Mounting Points

• and VESA Compatible75x75mm100x100mm

Package Contents

• VESA Adapter Mount For NUC () x 1A

• M3 x 5mm Screws () x 4B

• M3 x 16mm Screws () x 4C

• M4 x 5mm Screws () x 4D

• M4 x 12mm Screw () x 4E

• M4 x 20mm Screws () x 4F

• M5 x 12mm Screws () x 4G

• M5 x 20mm Screws () x 4H

• Washers () x 4I

• Spacers () x 8J

• Quick-Start Guide x 1

Requirements

For the latest requirements, please visit www.startech.com/DOCK-NUC-VESA-MOUNT

• Phillips head screwdriver

• (Optional) NUC or Thin Client specic VESA mount bracket

Installation

Attach a NUC or Compatible Thin Client

1 Without a VESA Mount Bracket

Note: Use two Screws on either the vertical or horizontal Short Mounting Slots.

VESA Compatible Mount for Docking Station, NUC, or Thin Client

3

2

*Product may vary from image

B or C

A

1
