8-Input and Up to 12-Output

Video Wall Processor

and Matrix Switch

ALL-IN-ONE VIDEO WALL

AND MATRIX SOLUTION WITH

1080P FULL HD

RESOLUTION OUTPUT,

INTEGRATED CONVERTER &

SCALER

Quick Start Guide

VIDEO

Video Amplier

Bandwidth

3.2 Gbps

Input Video SignalVideo (TMDS) 0.5~1.0Vpp

Input DDC Signal5 volts

CompliancesHDMI 1.4, HDCP

Pixel Rates

Clock frequency beyond

165Mpix/second

Format4:4:4 and 4:2:2 data input formats

Resolution480p, 720p, 1080i, 1080p

Input Card Format4-port HDMI card

Output Card Format4-port HDMI card

Input SlotsUp to 8 (1 card)

Output SlotsUp to 12 (3 cards)

Video Type

RGB/YCBCR : 24/30/36-bits,

YCBCR: 8/10/12/16/20/24-bits

CONTROLS

RS-232

DB9 Female, 115200 BPS, N, 8, 1,

No ow control

TCP/IPRJ45, UDP

OTHER

Working Temperature0°C~+55°C

Storage HumidityUp to 95%

Weight20 lbs

Dimensions17 in (W) x 3.5 in (H) x 15 in (D)

Power Supply50/60Hz, 100~230 VAC

Consumption300W

SOFTWARE

Operating SystemWindows 7-10, Android 7 and above

NOTICE

The information contained in this document is

subject to change without notice. SmartAVI makes

no warranty of any kind with regard to this material,

including but not limited to, implied warranties of

merchantability and tness for particular purpose.

SmartAVI will not be liable for errors contained

herein or for incidental or consequential damages in

connection with the furnishing, performance or use of

this material.

No part of this document may be photocopied,

reproduced, or translated into another language

without prior written consent from SmartAVI

Technologies, Inc.

800.AVI.2131, 702.800.0005

2455 W Cheyenne Ave, Suite 112

North Las Vegas, NV 89032

SmartAVI.com

TECHNICAL SPECIFICATION

MXWALL-LP

WHAT’S IN THE BOX

PART NO.DESCRIPTIONQ-TY

MXWALL-LP1

8-Input 12-Output Video

Wall Processor and Matrix

Switch

CCPWR061Power supply cord

Quick Start Guide1
