© Copyright 2011 Smart-AVI, All Rights Reserved

NOTICE

The information contained in this document

is subject to change without notice. Smart-AVI makes

no warranty of any kind with regard to this material,

including but not limited to, implied warranties of

merchantability and fitness for any particular purpose.

Smart-AVI will not be liable for errors contained herein or for

incidental or consequential damages in connection with the

furnishing, performance or use of this material.

No part of this document may be photocopied, reproduced or

translated into another language without prior written consent

from Smart-AVI.

For more information, visit www.smartavi.com.

SmartAVI, Inc. / Twitter: smartavi

11651 Vanowen St. North Hollywood, CA 91605

Tel: (818) 503-6200 Fax: (818) 503-6208

http://www.SmartAVI.com

Delivers 4K/2K resolution while

switching four singals

between two displays.

www.smartavi.com

Quick-Start Guide

Technical Specications

What’s in the Box?

PART NO.QTYDESCRIPTION

HDR-4X2-Pro1HDR-4X2-Pro Router

Power Supply1PS5VDC2A

CONTROL

Front PanelTact Switch

IRVia Remote Control with IR Type 3

OTHER

PowerExternal 100-240 VAC/5VDC2A @10W

Dimensions6.625”W x 1”H x 2.875”D

Weight0.8 lbs.

ApprovalsUL, CE, ROHS Compliant

Operating Temp.32-131°F (0-55 °C)

Storage Temp.-4-185 °F (-20-85 °C)

HumidityUp to 95%

HDR-4X2-Pro

Rack Mountable Option

Our SmartRack is the perfect solution to allow

virtually all SmartAVI devices to be custom mounted

in a standard 19” server rack. The SmartRack is fully

adjustable and can secure/organize several devices.

VIDEO

FormatHDMI 1.3b [Deep Color, xvYcc color space supported]

DVI ComplianceSingle-link DVI-D 1.1

HDCP Compliance1.0/1.1

Video BandwidthSingle-link 340MHz [10.2Gbps]

Resolution480i,480p,720i,720p,1080i,1080p

Input Interface(4) HDMI[7.1ch audio & video]

Output Interface(2) HDMI[7.1ch audio & video]

ConnectorType A[19-pin female]

Maximum Distance25 ft.

4K/2K Resolution 4x2 HDMI

Matrix Switch
