User’s Manual

Desktop Monitor

MultiSync®

EA272Q

EA272U

MODEL: DD-EA272Q, DD-EA272QW, DD-EA272U, DD-EA272UW

The regulations for this monitor applied to one of model names listed above.

Please nd your model name in the label on the rear side of the monitor.

English−2

Table of Contents

DEAR CUSTOMER �� 2

Important Information ��3

TCO Certied .................................................................4

Safety Precautions and Maintenance ............................ 5

Recommended Use & Maintenance ............................ 10

Trademark and Software License ................................ 11

Supplied Components �� 11

Installation ��12

Parts name and Connecting Peripheral Equipment ��13

Connecting the Power Cord ��18

Using the cable holder �� 19

Turning Power On/Off ��20

Turning power on/off ....................................................20

Menu Items ��22

Displaying the menu screen ........................................22

Menu item details.........................................................23

Using the USB LAN function �� 32

Using the DP OUT MULTISTREAM function ��33

Using the HUMAN SENSING function ��35

Using the AUTO BRIGHTNESS function ��36

Troubleshooting ��37

Screen Image and Video Signal Issues ....................... 37

Hardware Issues ..........................................................39

Specications ��41

Compatible signal timing..............................................41

Product Specications .................................................42

Manufacturer’s Recycling and Energy Information ��45

Energy Saving .............................................................45

Addition explanation to EcoDesign Regulation ............45

DEAR CUSTOMER

Thank you for purchasing this product. To ensure safety and many years of trouble-free operation of your product,

please read the "Safety Precautions and Maintenance" carefully before using this product.

NOTE: 

Product warranty does not cover damage caused by improper installation. Failure to follow these recommendations

could result in voiding the warranty.

English−3

Important Information

To maintain compliance with EMC regulations, use shielded cables to connect to the following terminals: USB port, USB

Type-C port, HDMI input terminal and DisplayPort input terminal.

Supplier’s Declaration of Conformity

SHARP LCD MONITOR, DD-EA272Q, DD-EA272QW, DD-EA272U, DD-EA272UW

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device

may not cause harmful interference, and (2) this device must accept any interference received, including interference that

may cause undesired operation.

Responsible Party:

SHARP ELECTRONICS CORPORATION

100 Paragon Drive, Montvale, NJ 07645

TEL: (630) 467-3000 www.sharpnecdisplays.us

U.S.A. ONLY

WARNING:

An apparatus with CLASS I construction shall be connected to a MAIN socket outlet with a protective earthing connection.

(For Customers in U�K�)

IMPORTANT

• The wires in this mains lead are coloured in accordance with the following code:

GREEN-AND-YELLOW: “Earth”

BLUE: “Neutral”

BROWN: “Live”

• As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug

proceed as follows:

• The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug which is marked by the letter E or by the safety

earth symbol or coloured green or green-and-yellow.

• The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured black.

• The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured red.

• Ensure that your equipment is connected correctly. If you are in any doubt consult a qualied electrician.

“WARNING: THIS APPARATUS MUST BE EARTHED�”
