Features
USB Type-C - Female 2x
(Connect to host computer)
USB-A - Female 2x
(Connect to host computer)
Introduction
This premium Rocstor is a high-performance and fashionable design travel charger. It
is equipped with four USB connectors that are for output interfaces, this product
allows four devices to be charged at the same time. And all the two USB-A (3,4) ports
can convey 2.4A to total 3.4A, USB-C(2) port is specially designed for Type-C notebook
with total 18W (5V/3A,9V/2A) output. USB-C (1) port is specially designed for Type-C
notebook with total 65W-100W (5~15V/3A,20V/3.25A,20V/5A) output. The maximum
power output for single C1 port is 100W. It is suitable for Samsung, Android mobile
phones, iPads, Macbook and Chromebook. The unique design makes your life simpler
and easier.
1. Plug the DC connector of power adapter into the interface of the power station; then
plug the other connector of power adapter into socket.
2. Plug one USB connector of the cable into the interface of the charger and plug the
other connector of the cable into the electronic device ( Iphone, Samsung mobile
phone,MP3,PC, etc)
3. Please pull the USB connector out after the electronic equipment's fully charged.
Operation Notes
• For optimum performance, please use the power station according to the user manual.
• Please plug the power adapter into socket whose voltage range should be
100~240V /AC.
• Please unplug the power adapter after using.
Note: Our products have protection functions and the tips above are suggestions
just for safety.
• Do not use the power station with an electronic product which is not in conformity
with the specications, so as to avoid any problems caused by specication
mismatching.
• It’s normal that power station will be a little overheated in the use process.
• When the power station stops working under over-current, over- temperature or
short-circuit protection, please unplug the device after it automatically returns to
work, then you need to check whether the device is compatible with this charger.
• Do not let the power station close to re, such as stove, candles and etc.
• Do not let the power station soak into liquid, such as swimming pool, bathtub, etc.
• Do not wash the power station with corrosive cleaner.
Output:
Specication
Operation Procedures
Input/Output
Input 100-240VAC 50/60Hz
Output USB-C1 Output : （ ）5,9,15V/3A, 20V/5A 100W
USB-C2 Output :（ ）5V/3A,9V/2A 18W
USB A1+A2 Output: (5V/3.4A) 17W
USB C1 (65W)+USB C2 (18W)+USB A1 + USB A2 (17W)
Protection
Over current Yes
Short circuit Yes
Over temperature protection Yes
Over voltage Protection Yes
Performance
AC Leakage Current 5 max at 240VAC input
Ripple And Noise ≤200mV
Turn on delay time 3s max
Rise time 20mS
Eciency Conform VI energy eciency
Mechanical
Color White
Size (80.5 x 80 x 29.6) mm - (3.1 x 3.1 x 1.1) in
Weight 263 g - 0.57 lbs
Accessory User Manual
Environmental
Operating Temperature Range 0~25°C
Storage Temperature Range -20 ~ 80°C
Operating Relative Humidity 5% ~ 90% RH
Regulatory Approvals
Main unit IEC/EN/UL62368
Power Adapter UL
Warranty 1-Year
Package Contents
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the Packaging:
• Main unit x1
• User Manual x1
®
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Rocstor Premium 100W Smart USB-C™
Power Station Adapter
User Manual
Y10A245-W1
• Internal chip allows the 100-240VAC of input voltage.
• Four USB connectors for outputs:
USB-A (3), 4ports, provide 5V/3.4A in total, single port provides 5V/2.4A (max), and
equipped with intelligent IC and automatically identies the handheld devices
attached to the USB-C (2) port with 5V/3A,9V/2A, USB-C(1) port with
5~15V/3A,20V/3.25A ,20V/5A output is compliant with PD3.0 agreement.
• Accurate limited current output and over current protection.
• Overload protection and over voltage protection.
• Short circuit protection.
• Over temperature protection and remove the fault condition auto-recovery.
• Compliant with CE, FCC standards.
• Select precision electrical components, re line version, and imported re plastic.
• Portable and convenient to use.
• Specially designed for your Type-C supported devices.
