Abbildungen können nicht im Serien-Lieferumfang enthaltenes Zubehör darstellen / Illustrations can contain accessories, which are not included

in standard extent of delivery.

Abbildungen ähnlich, produktionsbedingte Abweichung vorbehalten / Illustration similar (in design), production-wise modications reserved

File: S:\shared-pool\Product-Documentation\T-Produktbeschreibung\30_n0t\Originale_Englisch_PA04\4007286_01016.doc

Erstelldatum / create date: 30.06.2006 12:39 Aktualisiert / up dated: 06.07.2006

Compressor

Art.-No.: 40.072.86

HK 8/24 – Set

Bar code: 4006825531930

Sales unit: 1 pc

The

HK

8

/24

the ideal equipment for

an ambitious

DIY an

d c

onvinces

through huge air capacity at a high pressure.

The mobile and oil-lubricated 1-cylinder compressor with direct coupled engine

is suitable for nearly all compressed

air application. Especially for coating, clamping, spraying and blowing up of balls and wheels.

Features:

-Pressure reducer (1)

-Pressure switch (2)

- 5 parts air pressure set consisting of:

pressure gauge (3)

blow-out gun (4)

spiral air hose (5)

spray gun with suction tumbler (6)

paint spray gun with oating tumbler (7)

-Air intake filter

-1 gauge for non-regulating vessel pressure

-1 gauge for regulating the working pressure

-Drain valve

-Back pressure valve

-Safety valve

-Undercarriage with push strap

-Main cable with earthed plug

-CE-vessel certicate to norm EN 286

-10 years warranty for the vessel

-No TÜV re-approval will be necessary

Technical data:

- Air intake capacity: 210 l/min

- Vessel size: 24 l

- Speed: 2850 min

-1

- Mains: 230 V ~ 50 Hz

- Motor power: 1.5 kW (2 PS)

- Operating pressure max: 8 bar

- Weight: 31.8 kg

- Packing dimension: 600 x 285x 630 mm

3

4

7

6

5

2

1
