User Manual
Thank you for choosing MOMAN product. Please read this manual
carefully before use and follow all instructions mentioned herein.
Power 210
V-mount Battery
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the
product to prevent mechanics damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external
force.
Do not attempt to disassemble the product. Doing so voids warranty.
Please have the product checked or repaired by authorized
technicians if any malfunctions happened.
Failure to follow all the instructions may result in mechanics damage.
Warranty does not apply to human errors.
It is normal for batteries to get hot during charging and use.
Keep the pole of the battery clean to ensure a better use experience.
Keep the battery in a cool and dry place for long-term storage. It is
recommended to keep the battery level above 50%.
After ten days, the battery will enter sleep mode automatically and
the output will be turned off. Press the indicator light button to
restore the output.
One both-way Type-c interface,can supply power to mobile device or
becharged with Type-c charger.
One both-way D-TAP interface,can supply power to other device or
becharged with this interface.
One USB-A interface,can supply power to other device.
Four level LED show the life and percentage of the battery capacity.
Built-in multiple control circuit, with temperature, voltage, current all-
round protection.
Caring For Your MOMAN Product Attention
Product feature
Appearance
① Switch Button
② Power indicator light
③ USB-C
④ USB-A
⑤ D-tap
⑥ V-Mount
⑦ BP Interface
During the charging process, the LED light shows the percentage of
remaining battery(25%,50%,75%,90%).
Batteries can be charged in the temperature range of 0~40° C, but
we recommend charging in the temperature range of 10~30° C to
ensure optimal battery performance.
At low temperatures, the internal resistance of the battery increases,
and the discharge time is shortened. When the load is heavy, the
The LED indicator from E to F respectively reprensents the percentage
of electric quantity : 25%、50%、75%、90% .
Charging Instruction
Discharging Instruction
Indicator Light
Capacity percentage
≥ 90%
75%~90%
50%~75%
25%~50%
＜ 25%
Troubleshoot （ : on : ash）
The battery runs out or is protected.Wait for a period
of time and check the indicator status.If the indicator
status is recovered, it indicates that the battery is
exhausted. Charge the battery as soon as possible.
Overcurrent, overtemperature or overvoltage of
charge. Please remove the battery and wait for the
battery to recover by itself. Overcharging please
put the battery in the shade, after a few minutes of
cooling, the battery will automatically recover; Remove
the battery and discharge it to reduce the battery
voltage.
The battery cannot be charged or discharged. Please
put the battery in a cool place and wait for the core
temperature to decrease ( recommended>30 minutes ).
Then hang the battery on the charger and try to charge.
If the battery is charged normally , the battery will return
to normal.
F → E （ : on : ash）
Unit 25 Basepoint Business Centre, Aviation Park, West Christchurch,
United Kingdom BH23 6NX
www.momanpower.com
@MomanGlobal
https://moman.co/youtube
Moman (UK) Limited
F → E
F → E
F → E
battery may be automatically cut o.
USB and D-TAP interface overload will cause output shutdown, press
the button to restore.
Please put on the rubber cover immediately after use to avoid dust.
The battery can discharge in-20℃ ~50℃ ;The battery performs best
when used in the temperature range of-10 ~40℃ .
Specication
Mount Type
Nominal Voltage
Capacity
Total Output
Charging Temperature
Discharging Temperature
Other
Parameters
Electromagnetic
Compatibility
Safety
Fall
V-mount
14.4V
210Wh/14.6Ah
200W/16A
16.8V
⎓
6A
65W(Max),5V/9V/12V/15V/20V(Max)
⎓
3.25A
Protocol:
1.BC1.2, IOS and SAMSUNG
2.QC2.0,3.0
3.FCP,SCP
4.PD2.0,3.0
5V/9V/12V/15V/20V(Max)
⎓
2.4A
100W/8A
16.8V
⎓
6A
10W,5V
⎓
2A
200W/16A
0~40℃ (suggest 10~30℃ )
-20~50℃ (suggest-10~40℃ )
EN55032,
EN55035
IEC62368,UN38.3
1.2m bare device falls freely
Interface
Electric
Pole×1
TYPE-C ×1
D-TAP ×1
USB×1
Output
Input
Output
Input
Output
lnput
Output
Dimension
Net Weight
105mm*79.6mm*73.7mm
1.023kg
Package List
User Manual x1USB-C Charging
Cable x1
Power 210
V-Mount Battery x1
