Parts and Instruction Manual

MPV31 Wide Area Vacuum

This manual is furnished with each new MINUTEMAN MPV-31. This provides the necessary

operating and preventive maintenance instructions. Operators must read and understand this

manual before operating or servicing this machine.

This machine was designed to give you excellent performance and eﬃ ciency. For best results

and minimal cost, please follow the general guidelines below:

· Operate the machine with reasonable care.

· Follow the manufacturers suggested maintenance instructions as provided in this booklet.

· Use original Minuteman supplied parts.

MPV31 Wide Area Vacuum

TECHNICAL SPECIFICATIONS

Model MPV-31

Model No. C27120-00 (120 Volt / 60Hz)

C27230-00 (230 Volt / 50Hz)

Sound Level 72dB

Dimensions (LxWxH) 37” x 31” x 18” (94cm x 79cm x 46cm)

Gross Weight 100 lbs. (45 kg)

Brush 30” (76cm)

Brush Speed 1550 RPM

Air Flow 212 CFM (100 ltr/sec)

Waterlift 63” (1600mm)

Bag Volume 1.2 Bushels

Wheels-Front

Technical Speciﬁ cations

MPV31 Wide Area Vacuum

Table of Contents

Technical Speciﬁ cations ..................................................................................................................... 2

Safety Instructions .............................................................................................................................. 4

Operating Instructions ........................................................................................................................ 5

Inspection ......................................................................................................................................... 5

Electrical - 115 Volt .......................................................................................................................... 5

Electrical - 240 Volt.......................................................................................................................... 5

Grounding Instructions ..................................................................................................................... 5

Machine Overview ............................................................................................................................... 6

Control Panel.................................................................................................................................... 6

Brush Pedal ...................................................................................................................................... 7

Oﬀ -Aisle Wand ................................................................................................................................. 7

Operation .............................................................................................................................................. 8

Operating Instructions ...................................................................................................................... 8

Maintenance ......................................................................................................................................... 9

Daily: ................................................................................................................................................ 9

Monthly: ............................................................................................................................................ 9

Brush Adjustment/Replacement ........................................................................................................ 9

Adjustment: ...................................................................................................................................... 9

Replacement: ................................................................................................................................... 9

Exploded Views ................................................................................................................................. 10

Main Assembly Front ...................................................................................................................... 10

Main Assembly Front BOM..............................................................................................................11

Main Assembly Rear ...................................................................................................................... 12

Main Assembly Rear BOM ............................................................................................................. 13

Main Assembly Bottom ................................................................................................................... 14

Diverter Assembly .......................................................................................................................... 15

115V Handle Assembly ................................................................................................................. 16

115V Handle Assembly BOM ......................................................................................................... 17

230V Handle Assembly ................................................................................................................. 18

230V Handle Assembly BOM ......................................................................................................... 19

Brush Assembly.............................................................................................................................. 20

Replacement Parts and Accessories ............................................................................................... 21

Warranty ............................................................................................................................................. 22
