WR SERIES

Front Door Installation Instructions

Instruction Sheet

I-00103 Rev C

OR

OR

TOOLS NEEDED

Hex Key (Provided)

FRONT VIEW

1) Determine hinge side.

NOTE: Hinge post ships with

washer pre-installed. If the

washer has come off during

shipping it must be re-installed.

2) Knock out cover

plate and discard.

3) Install male hinge to

cabinet, orient as shown.

4) Install female hinges to door,

orient as shown. Secure with

hex screw.

5) Install door on rack.

Hole facing

down
