Sivu 1/4
n
10,000-record on-board memory
n
Large 5.7 in. ¼ VGA backlit full color
screen
n
200 mA; 10 A and 25 A bond test with
high duty cycle
n
Selectable PASS/FAIL limits
n
Works with standard barcode scanners
PAT450
Portable Appliance Tester
PAT450
Portable Appliance Tester
DESCRIPTION
Operators of electric tools and other electrical equipment
must be protected from potentially dangerous flaws in
workmanship or wear and tear. The PAT450 is designed to
test portable electrical equipment for safe operation. The
tests conform to the latest editions of European regulations
and standards including VDE0701-0702 and the Code
of Practice for the In-Service Inspection and Testing of
Electrical Equipment in the UK.
The PAT450 has a memory capacity for storing up to 10,000
test results, and also 10 A and 25 A earth bond testing.
The unit also includes 1.5 kV and 3 kV flash testing, ideal
for tool rental outlets and service workshops where flash
testing is routine. It has a high duty cycle, with the design
tailored to fast testing, easy operation, and all-day use.
The PAT450 features a unique restart, so that when moving
the tester from one room to another, it restarts instantly
from the same menu where it was unplugged. This is a
significant timesaver, allowing more tests per day.
USB communication provides convenient download to a
standard USB memory stick. An on-board 10,000 record
memory provides interruption-free testing for improved
efficiency, with a large QWERTY keypad for fast data
entry. The instrument is capable of working with standard
barcode scanners and a thermal transfer barcode label
printer operating directly from the USB port. Thermal
transfer labels are highly resistant, stable and easily
available.
Five soft-keys give direct access to frequently-used
functions, accelerating navigation through menus and
increasing productivity. Both standard and customer
configurable test groups are available for fast, flexible asset
testing.
Accessories supplied include a combined earth-bond and
insulation test lead, an adapter for testing 120 V extension
leads, a laptop power supply adapter, and a carry case for
convenient product and lead storage. All instruments also
include download manager software, to enable data to be
converted into a CSV format which can be read directly on
a PC using Microsoft
®
Excel.
TYPE OF TESTS
Earth Bond and Continuity Tests
To verify the integrity of exposed metalwork on grounded
(Class I) appliances. Test current of 25 A is passed via a
remote probe, returning through the Ground pin of the
power plug.
Test currents of 10 A and 25 A are available for bond
testing. Where sensitive electronic equipment may be
damaged by high currents, 200 mA is selectable.
Insulation Test
To check that equipment conductors are isolated from
ground - 500 V dc; the live and neutral conductors are
linked; and the test voltage is applied between this link and
the ground pin. Where an appliance does not have an earth
connection (Class II), the remote probe is used to contact
anywhere on the external case of the equipment.
Where 500 V may damage sensitive equipment, the
PAT450 provides alternative methods of verifying insulation
integrity. A lower voltage of 250 V dc is selectable, or
alternatives such as a touch current test or substitute
leakage test can be performed.
