Sivu 1/8
H0-Rollenprüfstand 78102
2
Funktion
Rollenprüfstand zum Austesten oder Präsentieren
der Fahrfunktionen von H0-Fahrzeugen.
• Geeignet für Lokomotiven nach dem Mittel-
leitersystem (Märklin H0) und Zweischienen-
system (Trix H0).
• Geeignet für die Versorgung mit Gleichstrom
(max. 14 V), Wechselstrom (max. 16/24 V) oder
einem Mehrzugsystem (z. B. Märklin Digital oder
Systems, Trix Selectrix).
• Serienmäßig mit 3 Rollenbockpaaren für je eine
angetriebene Achse. Die Position dieser Bock-
paare ist variabel. Die Anzahl der montierten
Rollenbockpaare kann verändert werden.
• Zusätzlich 2 Gleisstücke zur Aufnahme von nicht
angetriebenen Achsen (Tender einer Dampflok,
Vor- oder Nachlaufgestell etc.). Das längere
Gleisstück (auf der Seite mit den Anschluss-
buchsen) ist an den Fahrstrom angeschlossen
und muss daher angeschlossen bleiben. Das
kürzere Gleisstück am anderen Ende kann
entfernt und ggf. durch weitere Rollenbockpaare
ersetzt werden.
• Erweiterbar mit dem Rollenbockpaar 78110 für
Modelle mit mehr als 3 angetriebenen Achsen.
• Erweiterbar mit dem Anzeigegerät 78111 zur
Ermittlung diverserer Geschwindigkeits- und
Zeitgrößen. Ein weiteres Rollenbockpaar mit
Sensor zur Geschwindigkeitsermittlung gehört
zum Lieferumfang von 78111.
• Länge des Rollenprüfstands: 375 mm.
Function
Static roller test stand to test or demonstrate the
drive functions of H0 vehicles.
• Suitable for locomotives using the central power
rail system (Märklin H0) and two-rail system
(Trix H0).
• Suitable for supply with DC current (max. 14 V),
AC current (max. 16/24 V) or use with a multiple
train system (e.g Märklin Digital or Systems, Trix
Selectrix).
• Comes as standard with 3 pairs of rollers for
each powered axle. The positioning of these
pairs of rollers can be varied. The number of
installed pairs of rollers can be changed.
• In addition, there are 2 track sections to accom-
modate non-powered axles (the tender on a
3
steam locomotive, front or rear bogie, etc.) The
longer track section (on the side with the con-
nector boxes) is connected to the drive current
and must therefore remain attached. The shorter
track section on the other end can be removed
and, if necessary, further pairs of rollers can be
added.
• Can be expanded using the additional pair of rol-
lers 78110 for models with more than 3 powered
axles.
• Can be expanded with the display device 78111
to show various speeds and times. An additio-
nal pair of rollers with a sensor to calculate the
speed is included in what is supplied with 78111.
• Length of the static roller test stand: 375 mm
(14‘ 3/4‘‘) .
Fonctionnement
Banc d’essai à rouleaux pour tester ou présenter
les fonctions de marche des véhicules H0.
• Convient aux locomotives appartenant au systè-
me à fil neutre (Märklin H0) et au système à deux
rails (Trix H0).
• Convient à une alimentation en courant continu
(de 14 V maxi), en courant alternatif (16/24 V
maxi) ou à un système multitrains (par ex. Mär-
klin Digital ou Systems, Trix Selectrix).
• En série avec 3 paires de supports à rouleaux
pour chaque essieu entraîné. La position de ces
paires de supports est variable. Le nombre de
paires de supports à rouleaux montés peut être
modifié.
• 2 rails supplémentaires permettant la mise en
place d’essieux non entraînés (tender d’une
locomotive à vapeur, châssis directeur ou
châssis tracté etc.) La partie plus longue du
rail (du côté avec les douilles de raccordement)
étant raccordée au courant de traction, elle doit
donc rester branchée. La partie plus courte, sur
l’autre extrémité, peut être retirée et complétée,
le cas échéant, par d’autres paires de supports à
rouleaux.
• Possibilité d’extension avec la paire de supports
à rouleaux 78110 pour les modèles avec plus de
3 essieux entraînés.
