Sivu 1/3
USB
TESTERS
METERS
&
ET920
USB-A and USB-C
Digital Meter
ET900
USB-A Digital Meter
ET910
USB-A Digital Meter
and Tester
ET900 USB-A DIGITAL METER TYPE A
The ET900 accurately and reliably measures and displays the USB port voltage,
current, capacity, energy and resistance simultaneously. It can function with any
USB-A port that has the ability to deliver power. It requires NO BATTERIES as it
draws power from the power source.
ET920 USB-A AND USB-C DIGITAL METER TYPE A AND C
The ET920 is a USB digital meter for both USB-A and USB-C ports. It accurately
and reliably measures and displays the USB port voltage, current, capacity, energy
and resistance simultaneously. It can function with any USB-A and most USB-C
ports that have the ability to deliver power. It requires NO BATTERIES as it draws
power from the power source.
Power Source
INPUT (USB-A)
Cable for easy access
to hard-to-reach ports
OUTPUT (USB-A)
at bottom
LCD Display
Monitor USB output: voltage,
current, capacity (
charge
delivered
mAh), energy (Wh),
resistance (calculated)
Qualcomm Quick
Charge
®
compatible
Voltage and current
overload detection
10-memory storage locations
Bright, easy-to-read
LCD screen
Power Source
INPUT (USB-C)
Cables for easy access
to hard-to-reach ports
LCD Display
OUTPUTS**
(USB-C and USB-A)
at bottom
**NOTE: USB-A and USB-C cables CANNOT be used simultaneously.
Mode Button
switches display
options, stores/
records data,
and resets data
memory
Mode Button
switches display
options, stores/
records data,
and resets data
memory
Power Source
INPUT (USB-A)
Monitor USB output: voltage,
current, capacity (
charge
delivered
mAh), energy (Wh),
resistance (calculated)
Qualcomm Quick
Charge
®
compatible
Voltage and current
overload detection
10-memory storage locations
Bright, easy-to-read
LCD screen
Power Source
INPUT (USB-A)
ET910 USB-A DIGITAL METER AND TESTER TYPE A
The ET910 is a USB digital for USB-A ports only. It meter and tester combination
accurately and reliably measures and displays the USB port voltage, current, capacity,
energy and resistance simultaneously. It can also test the maximum current delivery
capability of the USB port with fixed loads so user need not connect to an built-in
external load. It will function with any USB-A port that has the ability to deliver power.
It requires NO BATTERIES as it draws power from the power source.
Cable for easy access
to hard-to-reach ports
LCD Display
Mode Button switches
display options, stores/
records data, and
resets data memory
OUTPUT (USB-A)
at bottom
Test Load
Button
Test Load
LED Indicators
Measurement Range:
Voltage: 3- 20V DC
Current: 0.05 to 3A
Capacity used: 99.999mAh MAX
Energy delivered: 999Wh MAX
Resistance: 400 Ω MAX
Elapsed Time: Up to 999 hours,
59 min, 59 sec
Test maximum USB output
amperage:
0.5A, 1A, 2A, 3A
Monitor USB output: voltage,
current, capacity (
charge
delivered
mAh), energy (Wh),
resistance (calculated)
Qualcomm Quick Charge
®
compatible
Voltage and current
overload detection
10-memory storage locations
Bright, easy-to-read
LCD screen
Testing Mode
Press Test Load button multiple
times to cycle through each
amperage load test. Red LED
indicator light will be solid
indicating amperage testing.
Red LED indicator light
will shut off and “PASS” or
“FAIL” will display on screen
once test is complete.
Monitoring Mode
