JBL Consumer Products

250 Crossways Park Drive, Woodbury, NY 11797

8500 Balboa Boulevard, Northridge, CA 91329

800-336-4JBL(4525) (USA only)

www.jbl.com

©2001 JBL, Incorporated.

JBL is a registered trademark of JBL, Incorporated.

Part No.

ai5139

DESIGN GOAL:Bring the thrill of live performance and movie sound to

the homeenvironment bycalling on JBL’s professional engineering leadership.

SATELLITE TYPE:Titanium-laminate-dome tweeter, sealed enclosure

SUBWOOFER TYPE:

Bass-reflex enclosure

PORT DESIGN:FreeFlow™ flared

PROFESSIONAL REFERENCE:Cinema Loudspeaker Series

OWNER’S GUIDE

PRO SOUND

COMES HOME

™

PRODUCTLINE:

Surround Cinema Speakers

MODEL

SCS150

NUMBER:

SPECIFICATIONS

All features and specifications are subject to change without notice.

*Dolby and Pro Logic are trademarks of Dolby Laboratories.

DTS is a registered trademark of Digital Theater Systems, Inc.

SCS150 System

Frequency Response

30Hz 6dB)– 20kHz (–

Satellites

Recommended Power

10 – 100 watts

Impedance

8 ohms nominal

Sensitivity

88dB @ 1 watt/1 meter

Tweeter

One 1/2"titanium-laminate

dome, video-shielded

Midrange

Dual 3" drivers, video-shielded

Dimensions (H x W x D)

8-1/8" x 3-1/2" x 3-7/8"

206mm x 89mm x 99mm

Weight

2.65 lb/1.2kg

Center

Recommended Power

10 – 100 watts

Impedance

8 ohms nominal

Sensitivity

88dB @ 1 watt/1 meter

Tweeter

One 1/2"titanium-laminate

dome, video-shielded

Midrange

Dual 3" drivers, video-shielded

Dimensions (H x W x D)

3-1/2" x 8-1/8" x 3-7/8"

89mm x 206mm x 99mm

Weight

2.65 lb/1.2kg

Subwoofer

Amplifier

150 watts RMS

Woofer

10"

Enclosure

Bass reflex

Dimensions (H x W x D)

17-3/4" x 15-3/4" x 16-3/4"

451mm x 400mm x 426mm

Weight

35 lb/15.9kg
