JBL Consumer Products

250 Crossways Park Drive, Woodbury, NY 11797

8500 Balboa Boulevard, Northridge, CA 91329

800-336-4JBL(4525) (USA only)

www.jbl.com

©2001 JBL, Incorporated.

JBL is a registered trademark of JBL, Incorporated.

Part No.

ai5146

DESIGN GOAL:Bring the thrill of live performance and movie sound to

the homeenvironment bycalling on JBL’s professional engineering leadership.

SATELLITE TYPE:Titanium-laminate-dome tweeter, sealed enclosure

SUBWOOFER TYPE:

Bass-reflex enclosure

PORT DESIGN:FreeFlow™ flared

PROFESSIONAL REFERENCE:Cinema Loudspeaker Series

OWNER’S GUIDE

PRO SOUND

COMES HOME

™

PRODUCTLINE:

Surround Cinema Speakers

MODEL

SCS135

NUMBER:

SPECIFICATIONS

All features and specifications are subject to change without notice.

*Dolby and Pro Logic are trademarks of Dolby Laboratories.

DTS is a registered trademark of Digital Theater Systems, Inc.

SCS135 System

Frequency Response

35Hz 6dB)– 20kHz (–

Satellites

Recommended Power

10 – 100 watts

Impedance

8 ohms nominal

Sensitivity

86dB @ 1 watt/1 meter

Tweeter

One 1/2"titanium-laminate

dome, video-shielded

Midrange

One 3" driver, video-shielded

Dimensions (H x W x D)

4-3/8" x 3-3/16" x 3-3/4"

111mm x 81mm x 95mm

Weight

1.1 lb/0.5kg

Center

Recommended Power

10 – 100 watts

Impedance

8 ohms nominal

Sensitivity

86dB @ 1 watt/1 meter

Tweeter

One 1/2"titanium-laminate

dome, video-shielded

Midrange

Dual 3" drivers, video-shielded

Dimensions (H x W x D)

3-1/4" x 7-5/8" x 3-3/4"

83mm x 194mm x 95mm

Weight

1.89 lb/0.86kg

Subwoofer

Amplifier

100 watts RMS

Bass

8" woofer, bass-reflex

enclosure

Dimensions (H x W x D)

15" x 13" x 14"

381mm x 330mm x 356mm

Weight

30 lb/13.6kg
