Owner’s ManuaL

High Performance Loudspeaker

JBL

sCL-1

Enceinte hautes performances

Hochleistungs-Lautsprecher

Altavoz de alto rendimiento

Caixa de Som de Alto Desempenho

Высокопроизводительная аудиосистема

高性能扬声器

ハイパフォーマンススピーカー

고성능 라우드 스피커

PTBR

ZH-CN

English

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Clean only with a dry cloth.

6. Do not block any ventilation openings. Install this apparatus in

accordance with the manufacturer’s instructions.

7. Do not install this apparatus near any heat sources such as

radiators, heat registers, stoves or other apparatus (including

amplifiers) that produce heat.

8. Use only attachments/accessories specified by the

manufacturer.

9. Use only with the cart, stand, tripod, bracket

or table specified by the manufacturer or

sold with the apparatus. When a cart is used,

use caution when moving the cart/apparatus

combination to avoid injury from tip-over.

10. Refer all servicing to qualified service personnel. Servicing

is required when the apparatus has been damaged in

any way, such as when the power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into

the apparatus, or the apparatus has been exposed to rain or

moisture, does not operate normally or has been dropped.

Correct disposal of this product (Waste Electrical & Electronic

Equipment)

This symbol means the product must not be discarded as

household waste, and should be delivered to an appropriate

collection facility for recycling. Proper disposal and recycling helps

protect natural resources, human health and the environment.

For more information on disposal and recycling of this product,

contact your local municipality, disposal service, or the shop

where you bought this product.

RoHS

This product is RoHS compliant.

This product is in compliance with Directive 2011/65/EU, and its

amendments, on the restriction of the use of certain hazardous

substances in electrical and electronic equipment.

REACH

REACH (Regulation No 1907/2006) addresses the production and

use of chemical substances and their potential impacts on human

health and the environment. Article 33(1) of REACH Regulation

requires suppliers to inform the recipients if an article contains

more than 0.1 % (per weight per article) of any substance(s) on the

Substances of Very High Concern (SVHC) Candidate List ('REACH

candidate list'). This product contains the substance "lead" (CAS-

No. 7439-92-1) in a concentration of more than 0.1% per weight.

At the time of release of this product, except for the lead

substance, no other substances of REACH candidate list are

contained in a concentration of more than 0.1% per weight in this

product.

Note: On June 27, 2018, lead was added to the REACH candidate

list. The inclusion of lead in the REACH candidate list does not

mean that lead-containing materials pose an immediate risk or

results in a restriction of permissibility of its use.

English

THanK YOu FOr CHOOsInG JBL

For more than 70 years, JBL has been involved in every aspect of music and film recording and reproduction, from live

performances to monitoring the recordings you play in your home, car or office.

We are confident that the JBL Synthesis loudspeaker you have chosen will provide every note of enjoyment that you

expect – and that when you think about purchasing additional audio equipment for your home, car or office, you will

once again choose JBL.

Please take a moment to register your product on our website at www.jblsynthesis.com. This enables us to keep you

posted on our latest advancements, and helps us to better understand our customers and build products that meet

their needs and expectations.

All features and specifications are subject to change without notice.

PaCKaGe COnTenTs

1x SCL-1 1x Grille 1x Quick Start Guide

If you suspect that there has been shipping damage, report it immediately to your dealer. We recommend that you

keep the box and packing materials for future use.

COnTenTs

THANK YOU FOR CHOOSING JBL

......................................................................................................................... 3

PACKAGE CONTENTS ............................................................................................................................................ 3

SPEAKER PLACEMENT ........................................................................................................................................... 4

LEFT AND RIGHT SPEAKERS ............................................................................................................................ 4

CENTER CHANNEL SPEAKER ........................................................................................................................... 4

5.1-CHANNEL SYSTEMS ................................................................................................................................... 6

7.1-CHANNEL SYSTEMS ................................................................................................................................... 6

GENERAL INSTALLATION NOTES ............................................................................................................................ 7

CONNECTING THE SPEAKERS TO AMPLIFICATION ................................................................................................ 7

PREPARING THE HOOK-UP WIRE ..................................................................................................................... 7

BI-WIRE OR BI-AMPLIFIER OPTIONS ................................................................................................................. 8

LF and HF NETWORK CONNECTIONS .................................................................................................................... 9

Default Setting with Built-In LF and HF Network Connection ............................................................................... 9

Bypass Setting without Built-In LF and HF Network Connection. ........................................................................ 10

CARING FOR YOUR SPEAKERS ............................................................................................................................ 10

SPECIFICATIONS .................................................................................................................................................. 11

DIMENSIONS ........................................................................................................................................................ 11
