Sivu 1/20
SPECIFICATIONS
All features and specifications
are subject to change without notice.
* Trademarks of Dolby Laboratories.
DTS is a registered trademark of Digital Theater Systems, Inc.
PS1400
Powered Subwoofer
Built-In Amplifier Power Output
400 Watts
Sensitivity (2.83V/1m)
91dB
Frequency Response (–6dB)
28Hz to 130Hz
Crossover Frequency
130Hz
Low-Frequency Transducer
LE14H-3 14" Aquaplas
™
-cone
woofer with rubber surround, 4"
edge-wound copper voice coil,
and cast-aluminum basket
Baffle
IsoPower™
Ports
2 FreeFlow™ flared
Terminals
5-Way, gold-plated binding posts
Dimensions (H x W x D)
19" x 20" x 15"
(483mm x 508mm x 381mm)
Plus grille and spike feet
Weight
80 lb (36kg)
PT800 Satellites
Recommended Amplifier
Power Range
50 – 250 Watts
Nominal Impedance
8 Ohms
Sensitivity (2.83V/1m)
91dB
Frequency Response (–6dB)
80Hz to 22kHz
Crossover Frequencies
650Hz, 3200Hz
High-Frequency Transducer
1" Pure-titanium dome with
rubber surround, shielded, with
EOS
™
waveguide
Midrange Transducer
4" Titanium inverted dome with
rubber surround and cast-
aluminum basket, shielded
Low-Frequency Transducer
8" Titanium-alloy inverted dome
with rubber surround and cast-
aluminum basket, shielded
Baffle
IsoPower™
Ports
None (sealed enclosure)
Network
Straight-Line Signal Path
™
(SSP)
Terminals
5-Way, gold-plated binding posts
Dimensions (H x W x D)
24" x 13-1/2" x 6"
(610mm x 343mm x 152mm)
Plus grille
Weight
37 lb (17kg)
PC600 Center
Recommended Amplifier
Power Range
50 – 250 Watts
Nominal Impedance
8 Ohms
Sensitivity (2.83V/1m)
91dB
Frequency Response (–6dB)
80Hz to 22kHz
Crossover Frequencies
800Hz, 3500Hz
High-Frequency Transducer
1" Pure-titanium dome with
rubber surround, shielded, with
EOS
™
waveguide
Midrange Transducer
4" Titanium inverted dome with
rubber surround and cast-
aluminum basket, shielded
Low-Frequency Transducer
Dual, 6," titanium-alloy inverted
domes with rubber surround and
cast-aluminum basket, shielded
Baffle
IsoPower™
Ports
None (sealed enclosure)
Network
Straight-Line Signal Path
™
(SSP)
Terminals
5-Way, gold-plated binding posts
Dimensions (H x W x D)
11-5/8" x 26-7/16" x 7-1/4"
(295mm x 672mm x 184mm)
Plus grille
Weight
32 lb (15kg)
OWNER’S GUIDE
PRODUCT
LINE: Performance
™
Series
MODELS: PS1400, PT800, PC600
DESIGN GOAL:
Bring the thrill of live performance and movie sound to
the home environment by calling on JBL’s professional engineering leadership
TWEETER:
1-Inch, Pure-Titanium Dome with Rubber Surround, Mounted
in EOS
™
Waveguide
MIDRANGE:
4-Inch, Titanium Inverted Dome with Rubber Surround and
Cast-Aluminum Basket
LOW-FREQUENCY:
Titanium-Alloy Inverted Dome with Rubber Surround
and Cast-Aluminum Basket in PT800 and PC600; 14-Inch Aquaplas
™
with
Rubber Surround, 4-Inch Edge-Wound Copper Voice Coil and Cast-Aluminum
Basket in PS1400
PROFESSIONAL REFERENCE:
Studio Monitor and Cinema
Loudspeaker Series
JBL Consumer Products
250 Crossways Park Drive, Woodbury, NY 11797 USA
8500 Balboa Boulevard, Northridge, CA 91329
800-336-4JBL (4525) (USA only)
www.jbl.com
©2001 JBL, Incorporated.
JBL is a registered trademark of JBL, Incorporated.
Part No.
336608-001
PRO SOUND
COMES
HOME
™
X + 0 + Y
2
0M
HZ
OWNER’S GUIDE
PRODUCT
LINE: Performance
™
Series
MODELS: PS1400, PT800, PC600
DESIGN GOAL:
Bring the thrill of live performance and movie sound to
the home environment by calling on JBL’s professional engineering leadership
TWEETER:
1-Inch, Pure-Titanium Dome with Rubber Surround, Mounted
in EOS
™
Waveguide
MIDRANGE:
4-Inch, Titanium Inverted Dome with Rubber Surround and
Cast-Aluminum Basket
LOW-FREQUENCY:
Titanium-Alloy Inverted Dome with Rubber Surround
and Cast-Aluminum Basket in PT800 and PC600; 14-Inch Aquaplas
™
with
Rubber Surround, 4-Inch Edge-Wound Copper Voice Coil and Cast-Aluminum
Basket in PS1400
PROFESSIONAL REFERENCE:
Studio Monitor and Cinema
Loudspeaker Series
2
For more than 50 years, JBL
has been involved in every
aspect of music and film
recording and reproduction,
from live performances to the
recordings you play in your
home, car or office.
We’re confident that the JBL
system you have chosen will
provide every note of
enjoyment that you expected –
and that when you think about
purchasing additional audio
equipment for your home, car
or office, you will once again
choose JBL.
Please take a moment to
complete the enclosed profile
card. It enables us to keep you
posted on our latest advance-
ments, and helps us to better
understand our customers and
build products that meet their
needs and expectations.
JBL Consumer Products
THANK YOU FOR CHOOSING JBL
This declaration applies to models PC600 and PT800 only. Information
regarding model PS1400 is included separately with that model only.
THE PERFORMANCE SYSTEM
The Performance System is an
extremely high-performance
speaker system intended for
uses ranging from premium
two-channel stereo all the way
to 5.1, 6.1 or 7.1 multi-channel
home-theater applications. The
system is modular and consists
of only three system elements:
• A PS1400 powered subwoofer
module incorporating a 14"
driver and internal 400-watt
class D amplifier.
• A PT800 tower module which
contains an 8" mid-bass driver,
a 4" midrange driver and a 1"
dome tweeter with integral
waveguide.
• A PC600 center module which
contains dual 6" drivers and
the same midrange and
tweeter elements as the
tower.
The acoustic behavior of the
PT800 tower and PC600 center
has been matched, giving the
added system flexibility of using
either PT800 towers or PC600
centers at any of the five, six or
seven speaker locations around
the room.
The system is intended for
room sizes of up to 3500 cubic
feet with two subwoofers. If a
larger room is being used, it
is suggested that additional
subwoofer modules be used.
Almost any home installation
can be accommodated by the
use of multiple modules.
The PT800 tower and PS1400
subwoofer can be docked
(stacked), resulting in a
traditional floorstanding
speaker system that can be
used in the front or surround
speaker positions. This system
can be used passively, or in a
bi-amp mode by using the
crossover capabilities of a
high-quality AV receiver or
separates. The PS1400
subwoofers can also be used
as traditional units placed
around the room with the PT800
towers and/or PC600 centers
being stand-, wall-, or
bookshelf-mounted. Both the
PT800 and PC600 speakers
come with wall-mounting
brackets.
Important Note: Do not send a
full-range amplified signal
directly to the PT800 tower
module. The PT800’s are not
designed to reproduce low
bass without a PS1400
powered subwoofer. For
optimum performance, the
PT800 should only receive
signals crossed over at 80Hz
and above.
Declaration of Conformity
We, Harman Consumer International
2, route de Tours
72500 Chateau-du-Loir
France
declare in own responsibility, that the
passive loudspeakers described in this
owner’s manual are in compliance with
technical standards:
EN 50081-1:1992
EN 50082-1:1992
Steen Michaelsen
Harman Consumer International
Chateau-du-Loir, France. 2/01
