IN-WALL SPEAKERS
OWNER’S MANUAL
Rev 07.01.2019
urin Exceence™ Manufacturin Exceence™
Man
nce
™ Manufacturin Exceence™
Manufacturin Ex
Exceence
™ Manufacturin Exceence™
Manufact
Manufacturin Exceence
™
Manufacturin Excee
Manufacturin Exceence
™ Manufacturin Exceence™
urin Exceence
™ Manufacturin Exceence™
Man
nce
™ Manufacturin Exceence™
Manufacturin Ex
Exceence
™
Manufacturin Exceence
™
Manufact
IN-WALL SPEAKERS
Please read the following instructions carefully before installing your Induction Dynamics ® freestanding speakers. If you have
any questions regarding installation that are not answered in the following directions, please contact your local sound contractor
or the Induction Dynamics®/MSE Audio® technical support team. Contact information can be found on the back of the manual.
General Information
Your speakers and amplier come in a high quality nish that is both attractive and durable. To clean, use a soft, damp cloth. If
your drivers become dusty, dust them with a paintbrush or a brush vacuum attachment. Do not use a strong or abrasive cleaner.
The grille is covered in acoustic cloth. To keep your grille clear of debris, we recommend you use a lint roller (like you would use
on clothes).
Do not use bass or loudness contour controls. Induction Dynamics’ subwoofers produce very low frequencies without these
controls. Use of these controls will make the bass sound “boomy”, obscure higher frequencies, and possibly cause damage
due to excessive cone excursion.
Speaker location: The in-wall speakers mount between wall studs and should be placed in accordance with the speaker’s
application (mains, surrounds, or stereo speakers).
The height of the speaker should be determined by locating the tweeter near ear level. The tweeter reproduces high-frequency
audio, which our ears perceive as most directional, so we are most attuned to their placement and level. As you make your
decision, consider whether people will be standing or sitting in the listening area. The speakers may be mounted upside down
(tweeter nearest oor) to achieve the proper tweeter level with the look of a higher mounted speaker.
Speaker Wiring: Use approved wire designed for in-wall or exposed use, as appropriate for your installation. For the in-walls,
we recommend using high-quality speaker wire that is 12 gauge or lower, with easily visible polarity coding to make your
connections. The following chart identies minimum gauge requirements for various lengths. See your local dealer or installation
contractor for more information.
Length in Feet
Up to 18’
Up to 29’
Up to 51’
AWG Size & Stranding
14 Gauge (19/27)
12 Gauge (65/30)
10 Gauge (105/30)
Wire Length / Minimum Gauge
Requirements
Installing the Easy-Mount Box Into the Wall
1. The in-walls are shipped preassembled with the faceplate attached to the easy-mount box with bolts. In order to install the
in-wall easy-mount box into the wall, you will rst need to separate the faceplate from the box. First, remove the grille mounting
anges, using the grille mounting ange driver. Note that there may be shims under some of the grille mounting anges. You will
need to save these shims to use when you reinstall the faceplate. Then unscrew the faceplate mounting bolts using a 1/4” hex
key or driver. You will later reattach the faceplate with these same faceplate mounting bolts.
2. There are two speaker wire access holes located at the top of the easy-mount box. The box comes with a solid grommet
preinstalled in the large hole and a small size grommet preinstalled in the smaller hole. The grommet hole size you will need
depends on the size of the wire you are putting through the hole. In the parts pouch you will nd a selection of large and small
grommets that have holes through them of various sizes. Use a grommet of the appropriate size to get a snug t around the
speaker wire where it enters the box. Put a solid grommet in the other hole. Make sure there is enough extra speaker wire
feeding into the box for easy handling of the loudspeaker faceplate.
3. Place the easy-mount box into the mounting hole.
4. Snug the Stud Grabber™ bolts against the left and right wall studs just enough to cause the easy-mount box to be suspended
in the cutout opening. Do not overtighten these bolts to avoid distorting the studs or box. Make all necessary adjustments to
level and position the easy-mount box in the wall. The preferred method is a small level held against the inner side of the easy-
mount box to make sure it is perfectly vertical. Upon completion, the box should be level and centered in the cutout opening
with the box gasket protruding 1/4” out from the drywall surface.
5. Tighten the Stud Grabber lock nuts with a wrench.
6. Place the 4” stud screws into the hole in the inside of the Stud Grabber bolts. Carefully pound them in about 1/4” with a
hammer to get the threads started. Tighten each of the screws with a #2 square head screwdriver until the screws are snug.
Installing the Faceplate
While installing the faceplate, we recommend that an assistant help hold the faceplate. Be careful working with the assembly
that you don’t damage any of the speaker components. If the midrange gets dented in, you can work it back out with your
ngertips or use a vacuum cleaner to suck it out.
1. Hold the speaker faceplate up to the wall opening and attach the speaker wire to the terminal block on the back of the
faceplate, observing the proper polarity. To make the connections to the terminal block, solder or crimp with high pressure the
insulated fork terminals provided in your parts packet. Soldering is best. For in-wall, use make sure the compensator switch is
in the proper position.
2. Position the speaker faceplate over the easy-mount box. Gently move it around from side to side and up and down until
the rubber gasket slides around the faceplate mounting inserts. Screw in the faceplate mounting bolts, gently tightening each
one a little at a time, until the faceplate is approximately 1/32” from the drywall all around. DO NOT TIGHTEN THE BOLTS ANY
FURTHER. The faceplate should not contact the drywall. This avoids any vibration or distortion of the drywall.
