TOUCH CONTROL PANEL

WASH CYCLE TABLE

PRODUCT DESCRIPTION

1. Top

2. Detergent dispenser drawer(The detergent

dispenser drawer is located inside the machine and can be

accessed by opening the door)

3. Control panel

4. Handle

5. Porthole door

6. Drain pump (behind the plinth)

7. Plinth (removable)

8. Adjustable feet (2)

DETERGENT DISPENSER DRAWER

Compartment 1: Pre-wash detergent

(powder)

Compartment 2: Washing detergent (powder

or liquid)

If liquid detergent is used, the removable plastic

partition A (supplied) should be used for proper

dosage. If powder detergent is used, place the

partition into slot B.

Compartment: Additives (fabric softeners,

etc.)

We recommend that the maximum level indicated by

the grille is not exceeded, and that concentrated fabric softeners are diluted.

! Use powder detergent for white cotton garments, for pre-washing, and

for washing at temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

! To remove the drawer, press lever C and pull the drawer outwards.

1

2

180

210

150

120

90

60

B

A

C

1.

3.

2.

5.

7.

6.

8.

4.

GB

Quick Guide

THANK YOU FOR PURCHASING A HOTPOINT PRODUCT.

To receive more comprehensive assistance, register the

appliance on www.hotpoint.eu/register

Prior to using the appliance, carefully read the Safety and installation instructions.

Prior to using the appliance, the bolts used for transport must be removed. For detailed

instructions on the removal procedure, consult the safety and installation instructions.

GREEN

1

2

3

DISPLAY

678

910

45

11

12

1. ON/OFF button with indicator light

2. WASH CYCLE SELECTOR knob

3. Buttons M1-M2-M3

4. TEMPERATURE button

5. SPIN button

6. GREEN indicator light

7. START/PAUSE button with indicator light

8. WASH CYCLE PHASE icons

9.CONTROL PANEL LOCK indicator light

10.LOCK indicator light

11. DELAYED START button

12. OPTION buttons

Max load 11 Kg

Power consumption in o -mode 0.5 W / in left-on mode 8 W

Detergents and additives

Recommended

detergent

Residual

dampness % (***)

Energy

consumption kWh

Total water lt

Laundry

temperature °C

Programme

Temperatures

Max. spin

speed (rpm

Max

load

(kg

Duration

(h : m)

PrewashWash

Fabric

softener

PowderLiquid

SettingRange12

Spin + Pump out *––140011.0**––––––––

Eco 40-60 (1)40 °C40°C

135111.04:00–



530.956135

13515.53:00–



530.586132

13513.02:10–



530.434332

20°C20 °C

- 20 °C

140011.01:50–



–



54.50.209522

Synthetics Resistant (3)40°C

- 60°C

12005.52:55



350.8380

43

Cotton (2)

40°C

- 60°C

140011.03:55–



491.1410745

Multi Colour20°C

- 20°C

140011.0**–



–



––––

Darks30°C

- 30°C

8006.0**–



–



––––

Bed&Bath60°C

- 60°C

140011.0**



––––

Whites

60°C

- 90°C

140011.02:40



541.9010055

Duvets30°C

- 30°C

12003.5**–



–



––––

Ultradelicates30°C

- 30°C

600 (****)1.0**–



–



––––

Mix 30’30°C

- 30°C

1200 (****)5.50:30–



–



710.2150

27

Steam Refresh–––2.0**–––––––––

Anti Allergy Delicate40°C

- 40°C

14005.5**–



–



––––

Wool40°C

- 40°C

8002.5**–



–



––––

Rinse––140011.0**––



––––––

 Dosing required  Dosing optional

TOUCH CONTROL PANEL

To adjust the settings, gently press the icon inside

the sensitive (touch control) area as illustrated in the

gure.

This data may dier in your home due to changing conditions in inlet water temperature,

water pressure etc. Approximate programme duration values refer to the default setting of

the programmes, without options.

The values given for programmes other than the Eco 40-60

programme are indicative only.

Note: 10 minutes after the START, the machine will recalculate the time remaining until the end of

the wash cycle on the basis of the load inside it; this value will then be shown on the display.

1) - Test wash cycle in compliance with EU Ecodesign regulation 2019/2014. The most

ecient programme in terms of energy and water consumption for washing normally soiled

cotton laundry.

Note: spin speed values shown on the display can slightly diers from the values stated in

the table.

For all testing institutes:

2) Long cotton cycle: set cycle

at a temperature of 40°C.

3) Long synthetics cycle: set cycle at a temperature of 40°C.

* By selecting thecycle and excluding the spin cycle, the washer-dryer will drain only.

** The duration of the wash cycles can be checked on the display.

*** After programme end and spinning with maximum selectable spin speed, in default

programme setting.

****

The display will show the suggested spin speed as default value.
