Sivu 1/4
D) Specifications: 技术参数
E) Attention使用注意事项
DVR-300D/DVC DVR-630D/DVC
LED灯说明书
Panel Instruction Manual
DVR-300D DVR-630D DVR-630DVCDVR-300DVC
型号 ：Model no.
LED
个数
No. of LED bulbs
功率
Power
色温
Color Temperature
电压
Voltage
流明
LUX
（
LUX)
尺寸
Dimensions (LxWxH)
重量
Weight
选购配件
Optional Accessories
包含配件
Accessories Included
300pcs
19w
630pcs
40.3w
5500K-6000K5500K-6000K
15V/5A
28x12.5x28cm 45x14x38cm
1.4kg
感谢您选购锐鹰公司的产品！
如欲了解更多相关产品的信息，请联系您当地的经销商或访问我们的
网页。使用产品之前，请先仔细阅读说明书。
Thank you for purchasing FalconEyes’ products.
For further details of our related products, please contact your
local distributor or visit our webpage at www.falconeyes.com.hk
Thank you.
Please read this manual carefully before using this product.
E-mail: info@falconeyes.com.hk
Websit: www.falconeyes.com.hk
适配器
AC Adaptor
SP-AC15(15v/5A)
9V/3A
SP-AC9 ( 9v/3A)
0.5M(8300)
1M(1800)/2M(390)
0.5M(11000)
1M(3900)/2M(970)
FM1304_DVR-300/630/1280_Chinese_eng
0.8kg
布袋 /
电源箱
Carrying Bag
/
Power Pack
(
MV-AD2)
柔光面罩、相机支架
Diffusor, Camera Bracket(RFL-L)
DVR-300D/DVC DVR-630D/DVC
3000K-7000K
（可调色温
Adjustable
）
3000K-7000K
（可调色温
Adjustable
）
Ф102mm
3
中心孔径
Central Aperture
1.
请勿带电插拔：（不使用时应断开电源，即插入或拔出连接时应先
把电源开关关掉）
2.
非专业人士，请勿随便拆卸，否则后果自负。
3.
使用环境应保持干燥、通风注意防潮防水。
4.
产品表面有轻微的油渍及污渍请使用清洁布擦拭表面即可清除。
5.
请避免硬物将其划伤以至影响使用效果。
7.
使用产品时，请详细阅读说明书。
1.Make sure the power is off after use.
2.Do NOT plug/unplug when the power is still connected.
3.Since there can be high voltage inside the unit, Do NOT open or repair the unit yourself. If there is any
defect, please contact an experienced technician.
4.Keep the environment dry and ventilated when using the product. Do not leave or use the flash in humid
or dusty environment.
5.For best performance of LEDs, maintain cleanliness of LEDS by wiping the surface softly with clean cloth.
6.Do NOT apply pressure to the product.
7.Read this manual carefully before using the product.
B) Panel Diagram功能示意图
A) Product Overview产品概述
C) Operating Instructions操作说明
DVR
系列
LED
采用了独有的环型结构，适用于单灯摄影，并会给你的摄影带来一些意想不到
的精彩效果，比如无影、眼神光、增加影像的立方体感等 。
DVR
系列有多款不同泡数 LED 的灯，并有分可调色温和恒定色温的灯，客户可根据不同的用
光要求而选择不同的灯，是您的好帮手。
DVR
系列
LED
灯电路安全稳定，有调光功能，拥有亮度高色温稳定、节能及寿命长等优点。
LED DVR series applied with the unique ring structure which is suitable for single light shooting and may bright
some wonderful effect for your photography, for example, shadow less, eyes light, increasing the sense of
cube of the images, etc.
DVR series has many models which comes up with different numbers of LED and has diversify into colour
temperature adjustable and fixed colour temperature. Customers can use different model according to
different light requirements to make the shooting more effective.
LED DVR series has strengths in stable circuit, dimming function, high brightness , stable colour temperature,
energy saving and long life.
1
2
LED
灯泡
LED blubs
灯体
Lighting panel
电源开关
Power switch
相机支架
Camera Bracket
DC
电源插孔
DC power jack
普通调光后面板
Rear panel with dimming function
调白光旋钮
White Color temp. control dial
调黄光旋钮
Yellow Color temp. control dial
可调色温后面板
Rear panel with adjustable color temperature function
电源开关
Power switch
相机支架
Camera Bracket(RFL-L)
调光旋钮
Power Control Dial
DC
电源插孔
DC power jack
锁紧手柄
Fixation Handle
普通LED灯使用
LED Lighting with dimmer :
可调色温LED灯使用
LED lights with adjustable color temperature :
1.插入电源之前，请检查电源开关是否关闭状态。（电源开关拔到0是关闭状态拔到1是已打开状态。）
2.插入电源，打开开关后用户根据所需的光线扭动调光旋钮。
1. Please ensure the power is switched off before plugging the power cable into the socket (“0”=OFF, “1”=ON)
2. Power can be adjusted by the power control dial.
1.
插入电源之前，请检查电源开关是否关闭状态。（电源开关拔到
0
是关闭状态拔到
1
是已打开状态。）
2.
插入电源，打开开关后用户根据所需调节白光、黄光功率比例来调节灯的输出功率和色温，灯的输出
功率为黄光和白光功率之和
,
输出色温为
3000K-7000K
可调。
3.
用户如需暖色调，请将底下的黄光旋钮根据需要向右调节；当黄光调到最大，白光旋钮向左边调到最
小时，灯输出的功率为
50%
，色温为
3000K
。
4.
用户如需冷色调，请将上面的白光旋钮根据需要向右调节；当白光调到最大，黄光旋钮向左边调到最
小时，灯输出的功率为
50%
，色温为
7000K
。
5.
白光和黄光的输出
功率
相等时，色温为
5000K
；如当白光旋钮和黄光旋钮同时调到最大时，灯输出
的功率为
100%
，色温值是
5000K
。
1. Please ensure the power is switched off before plugging the power cable into the socket (“0”=OFF, “1”=ON)
2. Inserted into the power supply and switch on the power. User can adjust the power output and color
temperature of the LED by adjusting the white and yellow ratio as they desired. The LED output power is the sum
of yellow and white LED. The output color temperature will be 3000K-7000K adjustable.
3.If user desire for a warm colour temperature, please turn the yellow LED knob located at the bottom to the right
follow by the user’s need. When the yellow LED comes to full power and the white LED knob turn to the left into
minimum output, the LED panel output will be 50% and the colour temperature will be 3000k.
4.If user desire for a cold colour temperature, please turn the white LED knob located above yellow LED knob to
the right. When the white LED comes to full power and the yellow LED knob turn to the left into minimum output,
the LED panel output will be 50% and the colour temperature will be 7000K.
5.When the output of both white and yellow LED comes to equal, the temperature colour will be 5000K. When
both yellow and white LED output comes to 100%, the colour temperature will be 5000K.
