Sivu 1/7
Poable Bluetooth Speaker
ES20
Quick Sta Guide
Model: EDF286009
EDIFIER ConneX app
EN
1. EDIFIER ConneX app
2. What’s in the box?
Speaker
Note:
•Images are for illustrative purpose only and may dier from the actual product.
•For the need of technical improvement and system upgrade, information and
specications contained herein may be slightly dierent from actual product.
If any dierence is found, the actual product prevails.
6. Bluetooth stereo pairing
10. Specications
Total output power (RMS): 6 W
Frequency response: 93 Hz-19 kHz
Declaration for EU
Frequency Band: 2.402 GHz ~ 2.480 GHz
RF Power Output: ≤13 dBm (EIRP)
There is no restriction of use.
5. Bluetooth connection
This speaker suppos the simultaneous connection of two Bluetooth devices.
Connect to a device
1. If no device is connected, the speaker will auto-enter Bluetooth pairing mode after
powered on (LED blinking in blue). If not, press and hold the "+" and "-" buttons for
1.5 seconds.
2. On your device, select "EDIFIER ES20" in its Bluetooth device list to connect, and the
blue LED will be steady lit when the connection is established.
•To disconnect from the current Bluetooth device, press and hold the "+" and "-"
buttons for 1.5 seconds.
Connect to two devices
1. Connect to a device, and then press and hold the "+" and "-" buttons for 1.5 seconds
(LED blinking in blue).
2. On the second device, select "EDIFIER ES20" in its Bluetooth device list to connect,
and the blue LED will be steady lit when the connection is established.
3. On the rst device, select "EDIFIER ES20" in its Bluetooth device list to reconnect.
•Pause or stop playback on the current Bluetooth device before streaming audio from
the second one.
Note:
•Pin code for connection is "0000" if needed.
•To enjoy all Bluetooth functions of this product, make sure that your audio source
device suppos HFP, A2DP and AVRCP proles.
•If no device is connected in 10 minutes, the speaker will switch to Bluetooth hidden
mode. The blue indicator will blink slowly. In this mode, (1) new devices cannot nd
the speaker, but (2) for a device that exists in the pairing record of this speaker, you
can select "EDIFIER ES20" from its Bluetooth device list to reconnect. To exit from
Bluetooth hidden mode, press " " button on the speaker.
•After powered on, the speaker will reconnect to the last connected devices
automatically.
1.5s
Bluetooth
Settings
EDIFIER ES20
DEVICES
Bluetooth
2:12
x1
x1
11. Troubleshooting
Cannot connect to your Bluetooth device
•
Make sure that the distance between this product and your Bluetooth device
is less than 10 meters and there are no obstacles between them.
•
Make sure that no device is connected to this product via Bluetooth.
•
Make sure that this product is in Bluetooth pairing mode. If not, manually
switch it to this mode.
•
Resta this product, enable Bluetooth function on your Bluetooth device,
and then t again.
No sound
•
Make sure that this product is powered on.
•
Make sure that this product and your device is properly connected.
•
Make sure that the playback is not paused.
•
Make sure that this product and your device are not muted.
•
Increase the volume of this product and your device.
Noise coming from speakers
•
EDIFIER speakers generate little noise, while the background noise of some
audio devices are too high. Please unplug audio cables and turn the volume
up. If no sound can be heard at 1 meter away from the speaker, there is no
problem with this product.
To learn more about EDIFIER, please visit www.edier.com
For EDIFIER warranty queries, please visit the relevant count page on
www.edier.com and review the section titled Warranty Terms.
USA and Canada: seice@edier.ca
South America: Please visit www.edier.com (English) or
www.edierla.com (Spanish/Pouguese) for local contact information.
With this app, you can
•control play from the Bluetooth
source device,
•control the master volume,
•upgrade the rmware, and
•more functions.
Download EDIFIER ConneX app
1. With your sma device, scan the QR code on the quick sta guide or the
packaging.
•You can also search for "EDIFIER ConneX" in Apple App Store (iOS devices) or
Google Play (Android devices).
2. Download and install the app.
How to use this app
1. Connect your sma device with the speaker via Bluetooth.
2. In Bluetooth mode, open EDIFIER ConneX App on your sma device.
3. Tap the menu for settings and playback control.
Quick start guideStrap USB-C to USB-C audio cable
3. Charging
5V 2A
5-10
W
Note:
•Power input: 5 V 2 A
•"5" is the minimum power required by the radio equipment to charge.
"10" is the maximum power required by the radio equipment to achieve
maximum charging speed.
4. Power on/o
OFFON
1.5s
1.5s
Press and hold the " " button for 1.5 seconds to power on/o the speaker.
① ②
① ②
Bluetooth
Settings
EDIFIER ES20
DEVICES
Bluetooth
2:12
x2 x2
Pair two ES20 speakers to enjoy stereo sound.
1. Double press the " " button on the rst ES20. The white LED will be in breathing
pattern.
2. Double press the " " button on the second ES20. The white LED will be in
breathing pattern.
• Once the connection is established, the white LED on the rst ES20 will be steady
lit or blink rapidly, and the white LED on the second ES20 will light o.
3. Connect the rst ES20 to your Bluetooth device and sta playing.
• To exit the stereo mode, double press the " " button.
Note:
• The rst ES20 will work as the master speaker. You can control play on the rst
ES20.
• The rst ES20 will deliver the right channel audio and the second one is for the left
channel audio.
9. Light eects
x1 ： x2 ：
OFFON
1.5s
1.5s
8. Phone calls
x1
x1
7. Play control
