Sivu 1/31
DFE-580TX
10/100 Mbps PCI-Bus Fast Ethernet Server Card
Manual
Windows 2000
Windows 2003 Server
Fourth Edition (July 2005)
651DFE580055
Printed In China
RECYCLABLE
DFE-580TX
Contents
Introduction to D-Link Server Card Software 4.0 .........................................................................3
Key Features............................................................................................................................3
Important Information...................................................................................................................3
What’s New in D-Link Server Card Software v. 4.0..................................................................4
Requirements...........................................................................................................................4
Before You Install - A Checklist................................................................................................4
Quick Setup Guide.......................................................................................................................5
Installing D-Link Server Card Software for Windows 2000 and Windows 2003 Server............5
Verifying Protocol Information of the Array...............................................................................9
Using the D-Link Server Card....................................................................................................11
Software Statistics Utility ...........................................................................................................11
Scale ..................................................................................................................................15
Graph Detail .......................................................................................................................15
Graph Type.........................................................................................................................15
Protocol Stats Tab ..............................................................................................................16
Device Stats Tab ................................................................................................................16
Editing D-Link Server Card Software Arrays ..........................................................................17
Windows Event Log Messages..................................................................................................19
Product Registration ..................................................................................................................24
International Offices...................................................................................................................30
DFE-580TX
Introduction to D-Link Server Card Software 4.0
D-Link Server Card Software is a software-only solution that enables Windows NT, 2000, Windows 2003
Server and Linux systems (sold separately) to load-balance network traffic across two or more network
connections creating redundant data paths throughout the network. For a low per-system cost, you can
simultaneously eliminate the risk of downtime due to a network failure while more than tripling your
server's throughput.
D-Link Server Card Software is designed to work as a standalone solution or across the enterprise. D-Link
Server Card Software can be deployed on key servers or workstations as a great low-cost solution to
eliminate bottlenecks and provide enhanced fault tolerance. Alternatively, D-Link Server Card Software
can be deployed across the enterprise to eliminate all single points of failure and create redundant data
paths between any two points on the network for a complete end-to-end solution.
End-to-End Network Fault Tolerance
Unlike simple NIC trunking solutions that only detect link failures at the network adapter, D-Link Server
Card Software peers deep into the network to detect faults and intelligently reroutes traffic based on where
and what type of fault is detected. By pushing fault tolerance detection into the network, D-Link Server
Card Software enables you to design a network so th nts of failure between any at there are no single poi
two points. If a NIC, switch port, switch or cable fails, D-Link Server Card Software will detect it and
instantly reroute traffic.
Eliminate Bottlenecks Throughout the Network
To increase network performance, D-Link Server Card Software distributes traffic among multiple
network adapters on the server. The software assigns connections to different adapters in a round-robin
fashion as users access the server. This process effectively broadens bandwidth by a factor equal to the
number of adapters in the array. To the system, the multiple network connections appear as a single
network interface with a single IP address. To any clients, the system appears immediately available
without the delay of congestion typical during high-access periods.
Key Features
• Provides increased performance with network traffic load balancing.
• Performs load balancing on inbound and outbound traffic.
• Achieves over 2 Gbs with Gigabit adapter array or 380Mbs with a 4 100Mb adapter array.
• Provides instant failover without loss of data.
• Detects faults deep within the network and intelligently reroutes traffic.
• Can eliminate single points of failure between any two systems on the network.
• Remote management with Web-based Enterprise Manager.
• Compatible with any NIC card – not vendor-specific.
• Supports Ethernet, Fast Ethernet, Gigabit Ethernet.
• Provides detailed throughput graphing and reporting.
• Provides PCI Hot Plug support.
• Supports 802.3ad and FEC/GEC switch-based trunking.
Important Information
The following sections cover important information you need to successfully install D-Link Server Card
Software. Please read this section carefully. This information is intended to help you get up and running
quickly and minimize the "gotchas" that can waste hours of installation time.
