Sivu 1/4
18-Port Unmanaged Desktop PoE Switch
DES-1018P/DES-1018MP
The D-Link® DES-1018P/DES-1018MP 18-Port Unmanaged Desktop PoE Switch enables users
to easily connect and supply power to PoE-capable devices such as wireless Access Points
(APs), IP cameras, and IP phones. The DES-1018P/DES-1018MP can also connect other Ethernet
devices like computers, printers, and a Network Attached Storage (NAS) to t into any type of
network application.
Power Over Ethernet IEEE 802.3af
The DES-1018P/DES-1018MP features 8 or 16 ports (respectively) that support the IEEE 802.3af
PoE protocol. Each of the PoE ports can supply up to 15.4 watts, with a total PoE budget of 80 watts
(DES-1018P) or 246.4 watts (DES-1018MP), allowing users to attach an IEEE 802.3af-compliant
device to the DES-1018P/DES-1018MP without requiring additional power. PoE is especially
suitable for devices that are far from power outlets or when users want to minimize the clutter
of extra cables as power is supplied via the Ethernet cables themselves.
Expand Your Network
The addition of two Gigabit combo uplink ports means businesses can increase their network
bandwidth using the speed of Gigabit Ethernet while oering redundancy so voice and
surveillance data are transferred reliably. The combo design can increase bandwidth by oering
two Gigabit copper or ber connections, giving administrators more options for expansion.
Cut Your Energy Costs
To help small businesses save on operating costs, the DES-1018P/DES-1018MP supports IEEE
802.3az Energy Ecient Ethernet (EEE). This feature senses network trac to automatically put
ports that are not being used to sleep, powering them on only when they are required. The
DES-1018MP also features a smart fan that automatically adjusts itself to reduce power
consumption and noise whenever possible to conserve energy, so users can reinvest the cost
savings back into their business.2
Features
Versatile Connectivity
• 8 (DES-1018P) or 16 (DES-1018MP)
10/100 Mbps PoE ports
• Two Gigabit combo uplink ports
Reliability
• 2 kV surge protection for PoE ports
• IEEE 802.3x ow control
Easy Setup
• Plug-and-play installation
• Auto MDI/MDIX crossover for all ports
Green Features
• IEEE 802.3az Energy Ecient Ethernet
• Smart fan (DES-1018MP only)
• RoHS compliant
Power Your Devices
Supports IEEE 802.3af Power-over-Ethernet (PoE) to
power your PoE-capable network devices via Ethernet
cables without the need for power adapters
Reliability PoE Connections
Enhanced surge protection on all PoE ports protects
the switch when feeding power to outdoor PoE-
capable devices1
Flexible Connectivity
All downlink ports support 10/100 Mbps speeds, and
two Gigabit uplink ports provide a redundant, wired
speed connection for reliable networking
Product Highlights
DES-1018P/DES-1018MP
18-Port Unmanaged Desktop PoE Switch
Hassle-Free Setup
The DES-1018P/DES-1018MP is a Plug-and-Play device that requires no
conguration, so setup is simple and hassle-free. Simply connect the switch to
a network and then connect multiple computers, share les, and make Voice-
over-IP calls across the network. Support for Auto MDI/MDIX on all ports
eliminates the need for crossover cables when connecting to another switch
or hub. Auto-Negotiation on each port senses the link speed of a network
device (either 10 or 100) and intelligently adjusts for compatibility and
optimal performance. Combining the convenience of PoE, fast performance,
reliability, and ease of use, the 18-Port Unmanaged Desktop PoE Switch is the
ideal choice for adding PoE devices to a network.
Sample Conguration
Internet
Modem
Router
Desktop
Laptop
NAS
Outdoor AP
(PoE)
Outdoor
IP Camera
(PoE)
DES-1018P or
DES1018MP
NVR
Gigabit
Connection
Outdoor
IP Camera
(PoE)
DES-1018P/DES-1018MP
18-Port Unmanaged Desktop PoE Switch
Technical Specications DES-1018P DES-1018MP
General
Device Interfaces 8 10 / 100 Mbps PoE, 8 10 / 100 Mbps ports•
• 2 10 / 100 / 1000BASE-T / SFP combo ports
• 16 10 / 100 Mbps PoE ports
• 2 10 / 100 / 1000BASE-T / SFP combo ports
Standards • IEEE 802.3 10BASE-T Ethernet
• IEEE 802.3u 100BASE-TX Fast Ethernet
• IEEE 802.3z
• IEEE 802.3x Flow Control
• IEEE 802.3az Energy-Efficient Ethernet (EEE)
Switching Fabric 7.2 Gbps•
64 Byte Max. Forwarding Rate 5.36 Mpps•
Transmission Method • Store-and-forward
MAC Address Table • 8k
Packet Buffer 384 KB•
Media Interface Exchange Auto MDI/MDIX adjustment for all ports•
LED Indicators Per unit: Power•
• Per port: Activity / Link and Speed
• Per PoE port: Power fail, Power OK
Fan • •1 fan 1 Smart fan
PoE Standard IEEE 802.3af•
PoE Ports Ports 1~8 up to 15.4 W per port Ports 1~16 up to 15.4 W per port• •
PoE Power Budget 80 watts 246.4 watts• •
Surge Protection Ports 1~8 up to 2 kV Ports 1~16 up to 2 kV• •
Physical
Dimensions • 11” x 8.3” x 1.7” (280 mm x 210 mm x 44 mm)
Weight • 1.78 kg (3.92 lbs) • 2.15 kg (4.74 lbs)
Power • Internal AC input: 100 ~ 240 VAC, 50~60 Hz
Power Consumption Maximum Power Consumption: 102.6 watts (PoE on), •
14.3 watts (PoE off)
• Standby Power Consumption: 7.1 W / 100 V ,
8.3 W / 240 V
• Maximum Power Consumption: 301.6 watts (PoE on),
15.6 watts (PoE off)
• Standby Power Consumption: 9.3 W/100 V ,
10.5 W / 240 V
Temperature • Operating: 0 to 40 ˚C (32 to 104 ˚F) • Storage: -40 to 70 ˚C (-40 to 158 ˚F)
Humidity • Operating: 0% to 95% RH non-condensing • Storage: 0% to 95% RH non-condensing
MTBF • 395,864 hours • 361,802 hours
Heat Dissipation 349.9 BTU/h 1029.5 BTU/h• •
Certifications • FCC Class A
• CE
• CCC
• RoHS
• VCCI
• BSMI
• C-Tick
Safety CB•
• cUL
• LVD
• CCC
• BSMI
