The API TranZformer

®

GT

provides unsurpassed sonic sculpting by combining a legendary API 525

“feedback” type compressor circuit with an inductor-based tone control inspired by the vintage API 553

program equalizer in a versatile and robust guitar pedal/direct box with balanced and unbalanced outputs.

Features include independent tone and compression in/out footswitches, phase inverters on each output,

ground lift, clip indicator, transformer output, true hardwire bypass, and of course the classic API sound.

SIGNAL FLOW (from right to left) : Input > GAIN > COMP > TONE > Transformer Output

AUDIO CONTROLS

1. GAIN: Input level; +9dB to +30dB; More gain creates more compression

2. COMP (compression): Determines amount of compression (gain-reduction); Higher

numbers provide more compression (lower threshold)

3. CLIP LED: Illuminates to indicate Input Gain or Output stage (pre Level) clipping

4. TONE (equalizer): 3-band +/- dB EQ (see graph on page 2) 15

200Hz peaking EQ; low-end (body, warmth, power…)

1.5kHz peaking EQ; mid-range (presence, attack, articulation…)

5kHz shelving EQ; high-end (air,brightness,brilliance, edge…)

5. Output LEVEL: -inf. to 0dB attenuator; 0db (no cut) is fully clockwise

Sets level for ¼” unbalanced output only (balanced output level is xed)

FOOTSWITCHES

A. COMP (compressor): Engage/disengage compressor; lit LED when engaged

B. TONE (equalizer)Engage/disengage equalizer; lit LED when engaged :

C. BYPASS: Hardwired unbalanced bypass; lit LED when BYPASSED

GT GUITAR PEDAL USER GUIDE
